Onkyo HT-R290

22/53 PAGE
U001
P8001A SOCKET NSCT-21P2412 1 25052515
U001
P8002A SOCKET NSCT-9P2400 1 25052503
U001
P8003B PLUG NPLG-7P0962 1 25056012
U001
RL660 RELAY NRL-2P5A-DC24-129 1 25065563A
U001
RL660 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
U001
RL660 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
U001
RL662 RELAY NRL-2P5A-DC24-129 1 25065563A
U001
RL662 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
U001
RL662 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
U001
RL663 RELAY NRL-2P5A-DC24-129 1 25065563A
U001
RL663 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
U001
RL663 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
U001
RL667 RELAY NRL-2P5A-DC24-129 1 25065563A
U001
RL667 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
U001
RL667 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
U001
RL669 RELAY NRL-2P5A-DC24-129 1 25065563A
U001
RL669 or RELAY NRL-2P8A-DC24-144 ( 1) 25065590
U001
RL669 or RELAY NRL-2P5A-DC24-193 ( 1) 25065703
U001
RL691 RELAY NRL-1P10A-DC12-196 1 25065707
U001
RL691 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
U001
RL691 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
U001
RL692 RELAY NRL-1P10A-DC12-196 1 25065707
U001
RL692 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
U001
RL692 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
U001
RL693 RELAY NRL-2P5A-DC24-129 1 25065563A
U001
[TUNER UNIT]
U001
U131 PHT CP JSR1165-001recieving 1 24120143
U001
U132 PHT CP JSR1165-001recieving 1 24120143
U002
U002 U0020 + U0021 + U0022 + U0023 + U0024
U002
U0020
Display PC board ass'y BADIS-0654-1C
U002
U0021
Standby switch PC board ass'y BADIS-0655-1C
U002
U0022
Video PC board ass'y BAVD-0656-1C
U002
U0023
HP Jack PC board ass'y BAETC-0658-1C
U002
U0024
Primary Wiring PC board ass'y BAPS-0659-1C
U002
U002
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U002
[SEMI CONDUCTOR]
U002
D7002 ZENER D DZ2J082M0L 1 224760820R2
