HT-R370
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. <B> : Black model
<S> : Silver model
<DC> : 120V,Canadian model
<DD> : 120V,USA model
<MO> : 220/230-240V,Saidi Arabian model
EXPLODED VIEW PARTS LIST
<PP> : 230V,CE(European) country model
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
EXPLODED
U001 AF-AS AMPLIFIER PC BOARD BAAF-0002-1E 1 1B232502-1E N
<BPP>
EXPLODED
U001 AF-AS AMPLIFIER PC BOARD BAAF-0002-1D 1 1B232502-1D N
<BDC, BDD>
EXPLODED
U001 AF-AS AMPLIFIER PC BOARD BAAF-0002-1F 1 1B232502-1F N
<BMO, SMO>
EXPLODED
U0011
TRANS.SEL.TERMINAL PC BOARD
BAAF-0003-1E { 1} 1B232503-1E N
NSP included in "AF-AS"
<BPP>
EXPLODED
U0011
TRANS.SEL.TERMINAL PC BOARD
BAAF-0003-1D { 1} 1B232503-1D N
NSP included in "AF-AS"
<BDC
BDD>
EXPLODED
U0011
TRANS.SEL.TERMINAL PC BOARD
BAAF-0003-1F { 1} 1B232503-1F N
NSP included in "AF-AS"
<BMO
SMO>
EXPLODED
U0012
TRANS.SEL.TERMINAL PC BOARD
BAAF-0004-1E { 1} 1B232504-1E N
NSP included in "AF-AS"
<BPP>
EXPLODED
U0012
TRANS.SEL.TERMINAL PC BOARD
BAAF-0004-1D { 1} 1B232504-1D N
NSP included in "AF-AS"
<BDC
BDD>
EXPLODED
U0012
TRANS.SEL.TERMINAL PC BOARD
BAAF-0004-1F { 1} 1B232504-1F N
NSP included in "AF-AS"
<BMO
SMO>
EXPLODED
U0013
ETC PC BOARD
BAAF-0007-1E { 1} 1B232507-1E N
NSP included in "AF-AS"
<BPP>
EXPLODED
U0013
ETC PC BOARD
BAAF-0007-1D { 1} 1B232507-1D N
NSP included in "AF-AS"
<BDC
BDD>
EXPLODED
U0013
ETC PC BOARD
BAAF-0007-1F { 1} 1B232507-1F N
NSP included in "AF-AS"
<BMO
SMO>
EXPLODED
U002 DG-AS CPU/CODEC PC BOARD BADG-0022-1F 1 1B232522-1F N
<BPP>
Order
lease do at 2 units
EXPLODED
U002 DG-AS CPU/CODEC PC BOARD BADG-0022-1E 1 1B232522-1E N
<BDC, BDD>
Order
lease do at 2 units
EXPLODED
U002 DG-AS CPU/CODEC PC BOARD BADG-0022-1G 1 1B232522-1G N
<BMO, SMO>
Order
lease do at 2 units
EXPLODED
U003 DIS-AS DISPLAY PC BOARD BADIS-0036-1E 1 1B232536-1E N
<BPP>
EXPLODED
U003 DIS-AS DISPLAY PC BOARD BADIS-0036-1D 1 1B232536-1D N
<BDC, BDD>
EXPLODED
U003 DIS-AS DISPLAY PC BOARD BADIS-0036-1F 1 1B232536-1F N
<BMO, SMO>
EXPLODED
U0031
DISPLAY PC BOARD
BCDIS-0037-1E {1｝ 1B232537-1E N
<BPP>
EXPLODED
U0031
DISPLAY PC BOARD
BCDIS-0037-1D {1｝ 1B232537-1D N
