[SW TRM]
PCB-2
JL901B WIRE TRAP NPLG-5P588 1 25055626
PCB-2
P101A SOCKET NSCT-11P2104 1 25052207
PCB-2
P131 PIN JACK NPJ-1PDO554 1 25045772 <1E, 1F, 1G>
PCB-2
P2001A SOCKET IMSA-9142S-26A 1 25053235
PCB-2
P5501A SOCKET NSCT-7P2187 1 25052290
PCB-2
P5502A SOCKET NSCT-15P2195 1 25052298
PCB-2
P5503A SOCKET NSCT-9P2189 1 25052292
PCB-2
P5504A SOCKET NSCT-9P2189 1 25052292 <1E, 1F, 1G>
PCB-2
P701A SOCKET NSCT-33P2126 1 25052229 <1E, 1F, 1G>
PCB-2
P751A SOCKET IMSA-9618S-09A 1 25053334R2
PCB-2
P8001A PLUG IMSA-9111B-24 1 25056625
U003 DISPLAY PC BOARD (BADIS-0036-1D/1E/1F)
U00031 DISPLAY PC BOARD (BADIS-0036-1D/1E/1F)
U00032 VIDEO PC BOARD (BAVD-0036-1D/1E/1F)
U00033 POWER SUPPLY PC BOARD (BAPS-0039-1D/1E/1F)
U00034 HP JACK PC BOARD (BAETC-0040-1D/1E/1F)
CIRCUIT. N
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
PCB-3
U7042 REMO SENS NJL34H380A 1 241365
[SEMI CONDUCTOR]
PCB-3
D7002 ZENER D UDZS8.2B 1 224550820R2
PCB-3
D7033 ZENER D UDZS3.9B 1 224550390R2
PCB-3
D7152 LED SLI-343URC-TE7 1 225449T
PCB-3
D9001 DIODE RL1N4003 1 22380260T
PCB-3
D9005 ZENER D UDZS36B 1 224553600R2
PCB-3
D9011 DIODE D5SBA20 1 22380130F <1D, 1E, 1F>
PCB-3
D9014 C-DIODE KDS4148U 1 223283R2
PCB-3
D9014 or C-DIODE 1SS352 ( 1) 223234R2
PCB-3
D9014 or C-DIODE MA2J111 ( 1) 223279R2
PCB-3
D9015 C-DIODE KDS4148U 1 223283R2
PCB-3
D9015 or C-DIODE 1SS352 ( 1) 223234R2
PCB-3
D9015 or C-DIODE MA2J111 ( 1) 223279R2
PCB-3
D9016 ZENER D UDZS6.2B 1 224550620R2 <1D, 1E>
PCB-3
D9016 ZENER D UDZS6.8B 1 224550680R2 <1F>
