Onkyo HT-R370(B)(S) - PC Board Parts List - Semiconductors

EXPLODED
A360 LABEL (COVER) 1 29390767 N
EXPLODED
A362 LABEL HOOKUP-ONKYO 1 29363194 <BDC, BDD>
HT-R370
PC BOARD PARTS LIS
T
U001 AMPLIFIER PC BOARD (BAAF-0002-1D/1E/1F)
U0011 TRANS.SEL.TERMINAL PC BOARD (BAPS-0003-1D/1E/1F)
U0012 TRANS.SEL.TERMINAL PC BOARD (BAPS-0004-1D/1E/1F)
U0013 ETC PC BOARD (BAETC-0007-1D/1E/1F)
CIRCUIT. N
O
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
PCB-1
D5671 ZENER D MTZJ6.2B 1 224470622T
PCB-1
D5672 ZENER D MTZJ6.2B 1 224470622T
PCB-1
D5673 DIODE 1SS133 1 223163T
PCB-1
D5674 DIODE 1SS133 1 223163T
PCB-1
D5800 DIODE RL1N4003 1 22380260T
PCB-1
D5800 or DIODE GP104003E ( 1) 22380035T
PCB-1
D5801 DIODE RL1N4003 1 22380260T
PCB-1
D5801 or DIODE GP104003E ( 1) 22380035T
PCB-1
D5802 DIODE RL1N4003 1 22380260T
PCB-1
D5802 or DIODE GP104003E ( 1) 22380035T
PCB-1
D5803 DIODE RL1N4003 1 22380260T
PCB-1
D5803 or DIODE GP104003E ( 1) 22380035T
PCB-1
D5804 DIODE RL1N4003 1 22380260T
PCB-1
D5804 or DIODE GP104003E ( 1) 22380035T
PCB-1
D5805 DIODE RL1N4003 1 22380260T
PCB-1
D5805 or DIODE GP104003E ( 1) 22380035T
PCB-1
D6020 C-DIODE KDS4148U 1 223283R2
PCB-1
D6021 C-DIODE KDS4148U 1 223283R2
PCB-1
D6022 C-DIODE KDS4148U 1 223283R2
PCB-1
D6023 C-DIODE KDS4148U 1 223283R2
PCB-1
D6024 C-DIODE KDS4148U 1 223283R2
PCB-1
D6027 C-DIODE KDS4148U 1 223283R2 <1D, 1E, 1F>
PCB-1
D6031 DIODE 1SS133 1 223163T
PCB-1
D6032 DIODE 1SS133 1 223163T
