Onkyo HT-R530 Service Manual

72/74 PAGE
PCB3
RL6605A TAPE TAPE(CLOTH-16U) (1) 29110083
PCB3
RL6607 RELAY NRL-2P5A-DC24-158 1 25065618
PCB3
RL6607 or RELAY NRL-2P5A-DC24-129 (1) 25065563
PCB3
RL6607A TAPE TAPE(CLOTH-16U) (1) 29110083
PCB3
P901A PLUG 1-1123724-2 1 25056402
!
PCB3
P901Aor PLUG NPLG-2P631 (1) 25055675
!
PCB3
P902 AC OUTLET AC-181-UL-11V 1 25053030
!, <DD>
PCB3
P902 AC OUTLET AC-181-UL-11V 1 25053030
!, <DC>
PCB3
P902 AC OUTLET NSCT-2P2013 1 25052115
!, <PA>
PCB3
P912 PLUG 1-1123724-2 1 25056402
!
PCB3
P912 or PLUG NPLG-2P631 (1) 25055675
!
PCB3
P931A PLUG NPLG-5P0960 1 25056010
PCB3
P931B SOCKET NSCT-5P2185 1 25052288
PCB3
P1501 PIN JACK NPJ-10PDBY621 1 25045842
PCB3
P1501 or PIN JACK NPJ-10PDBY478 (1) 25045681
PCB3
P1503 PIN JACK NPJ-10PDBY621 1 25045842
PCB3
P1503 or PIN JACK NPJ-10PDBY478 (1) 25045681
PCB3
P1504 PIN JACK NPJ-5PDBY622 1 25045843
PCB3
P1504 or PIN JACK NPJ-5PDBY479 (1) 25045682
PCB3
P1505 PIN JACK NPJ-9PDGLRGLRGLR563 1 25045781
PCB3
P1506 PIN JACK NPJ-3PDGLR623 1 25045844
PCB3
P1588 TRM(SCREW) NEGITANSI M3 1 25065425
PCB3
P2005A SOCKET NSCT-13P2193 1 25052296
PCB3
P5019 TRM(SCREW) NEGITANSI M3 1 25065425
PCB3
P5504A PLUG NPLG-13P141 1 25055157
PCB3
P6000A SOCKET NSCT-5P2185 1 25052288
PCB3
P6001A SOCKET NSCT-5P2185 1 25052288
PCB3
P6002A SOCKET NSCT-5P2185 1 25052288
PCB3
P6003A SOCKET NSCT-5P2185 1 25052288
