Onkyo HT-R530 Service Manual

31/74 PAGE
PCB1
P311A SOCKET AS NSAS-20P1043 1 2002A392025UL
PCB1
P312 HOLDER (CLAMP) 1 27190540-1
PCB1
P702A SOCKET NSCT-29P2263 1 25052366
PCB1
P702A or SOCKET NSCT-29P2447 (1) 25052550
PCB1
P702B SOCKET NSCT-29P2263 1 25052366
PCB1
P702B or SOCKET NSCT-29P2447 (1) 25052550
PCB1
P721 ST JACK LGY2502-0200FC 1 25045696
PCB1
P871 PIN JACK NPJ-7PDB477 1 25045680
PCB1
P891 ST JACK MSJ-064-05A SR 1 25045783
PCB1
P891 or ST JACK YKB21-5005 (1) 25045724
PCB1
P2005 PLUG NPLG-13P0968 1 25056018
PCB1
E301 TRM NTM-1P233(M1969) 1 25060302
PCB1
E883 RETAINER (S) 1 27141931
PCB1
E891 RETAINER KANAGU 1 27141059
PCB1
JL831A WIRE HOL NSCT-7P898 1 25051111
PCB1
JL831B WIRE HOL NSCT-7P898 1 25051111
PCB1
JL891A WIRE HOL NSCT-5P896 1 25051109
U05 AMPLIFIER PC BOARD (NAAF-8523-1H/1J)
U06 SEC. TERMINAL-2 PC BOARD (NAPS-8524-1H/1J)
U07 SBR AMPLIFIER PC BOARD (NAETC-8525-1H/1J)
U08 THERMAL SENSOR PC BOARD (NAETC-8526-1H/1J)
PCB2
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO (SN) REMARKS
PCB2
Q5501 IC NJW1157B 1 22242193R3
PCB2
Q5502 IC NJU7311AM 1 22242209R2
PCB2
Q5503 IC NJM4580M-D 1 22241448R2
PCB2
Q5630 IC NJM4580M-D 1 22241448R2
PCB2
Q5640 IC AN34060A 1 22242205
