HT-R530
<Notes>
(B) : Black model only
(S) : Silver model only
<DD> : USA model only
<DC> : Canadian model only
<PA> : Australian model only
EXPLODED VIEW PARTS LIS
T
REF. NO. PART NAME DESCRIPTION Q'TY PART NO (SN) REMARKS
EV
A001 F BRACKET TX-SR503(B)MDD 1 27111389 (B)
EV
A001 F BRACKET TX-SR503(S)MDC 1 27111391 (S)
EV
A002 SCREW 3TTB+8B(CU)SR 36 801618
EV
A005 KNOB (SEL-L) 1 28326308 (B)
EV
A005 KNOB (SEL-L) 1 28326311 (S)
EV
A006 KNOB (SEL-R) 1 28326312 (B)
EV
A006 KNOB (SEL-R) 1 28326315 (S)
EV
A007 FACET (ST) 1 28198998A
EV
A013 WIRE TIE BSK-1 8 260208
EV
A014 CLIP CS-1U 2 27255004
EV
A015 CHASSIS --- 1 27100460A
EV
A017 TAPE TAPE(CLOTH-16U) (1) 29110083
EV
A018 HOLDER KGLS-22S 1 27190369
EV
A020 HOLDER KGLS-14RT 3 27190524
EV
A021 HOLDER HOLDER 2 27190991
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PAR
T
NUMBER SPECIFIED.
