Onkyo HT-R530

8/74 PAGE
EV
U16 CENTER SPEAKER TERMINAL PC board ass'y NAETC-8538-1H 1 1B068538-1H <DD>
EV
U16 CENTER SPEAKER TERMINAL PC board ass'y NAETC-8538-1H 1 1B068538-1H <DC>
EV
U16 CENTER SPEAKER TERMINAL PC board ass'y NAETC-8538-1J 1 1B068538-1J <PA>
EV
U17 VIDEO PC board ass'y NAVD-8539-1H 1 1B068539-1H <DD>
EV
U17 VIDEO PC board ass'y NAVD-8539-1H 1 1B068539-1H <DC>
EV
U17 VIDEO PC board ass'y NAVD-8539-1J 1 1B068539-1J <PA>
EV
U18 DRIVER AMPLIFIER PC board ass'y NAAF-8540-1H 1 1B068540-1H <DD>
EV
U18 DRIVER AMPLIFIER PC board ass'y NAAF-8540-1H 1 1B068540-1H <DC>
EV
U18 DRIVER AMPLIFIER PC board ass'y NAAF-8540-1J 1 1B068540-1J <PA>
EV
U19 TUNER UNIT TFCE1U114B 1 240134A <DD>
EV
U19 TUNER UNIT TFCE1U114B 1 240134A <DC>
EV
U19 TUNER UNIT TFCE1E512A 1 240135 <PA>
HT-R530
PC BOARD PARTS LIS
T
U01 DISPLAY PC BOARD (NADIS-8513-1V/1K)
U02 DSP PC BOARD (NADG-8514-1V/1K)
U03 SWITCH PC BOARD (NASW-8515-1V/1K)
U04 HEADPHONE JACK PC BOARD (NAETC-8516-1V/1K)
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO (SN) REMARKS
PCB1
U131 PHT CP TORX177L 1 24120127
PCB1
U132 PHT CP TORX177L 1 24120127
PCB1
U133 PHT CP TORX177L 1 24120127
PCB1
U821 REMO SENS GP1UM281XKVF 1 241361
PCB1
Q131 IC 74HCU04F 1 222740046R2
PCB1
Q151 IC TC74VHC541FT 1 22274541ER2TO
PCB1
Q151 or IC SN74AHC541PWR (1) 22274541IR2TI
PCB1
Q152 IC TC74HCT7007AF 1 222740077R2TO
