Onkyo HT-R530 Service Manual

53/74 PAGE
U11 POWER SUPPLY-1 PC BOARD (NAPS-8533-1H/1J)
U13 POWER SUPPLY-2 PC BOARD (NAPS-8535-1H/1J)
U14 SEC. TERMINAL-1 PC BOARD (NAPS-8536-1H/1J)
U15 SPEAKER TERMINAL PC BOARD (NAETC-8537-1H/1J)
U16 CENTER SPEAKER TERMINAL PC BOARD (NAETC-8538-1H/1J)
U17 VIDEO PC BOARD (NAVD-8539-1H/1J)
U18 DRIVER AMPLIFIER PC BOARD (NAAF-8540-1H/1J)
PCB3
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO (SN) REMARKS
PCB3
Q1503 IC LA7956 1 22241759
PCB3
Q1512 IC LA7956 1 22241759
PCB3
Q1513 IC LA7956 1 22241759
PCB3
Q1519 IC NJM2585L 1 22242243
PCB3
Q921 TR 2SC2458-GR 1 2212115
PCB3
Q921 or TR 2SC2458-BL (1) 2212116
PCB3
Q921 or TR KTC3199-GR (1) 2215864
PCB3
Q1501 TR RN1241-A 1 2213631
PCB3
Q1501 or TR RN1241-B (1) 2213632
PCB3
Q1502 TR RN1241-A 1 2213631
PCB3
Q1502 or TR RN1241-B (1) 2213632
PCB3
Q1504 TR 2SA933S-R 1 2213354
PCB3
Q1504 or TR 2SA933S-S (1) 2213355
PCB3
Q1504 or TR KTA1267-GR (1) 2215995
PCB3
Q1505 TR DTA114ES 1 2213510
PCB3
Q1505 or TR KRA102M (1) 2215770
PCB3
Q1506 TR DTA114ES 1 2213510
PCB3
Q1506 or TR KRA102M (1) 2215770
PCB3
Q1507 TR RN1241-A 1 2213631
