Onkyo HT-R530 Service Manual

30/74 PAGE
PCB1
S828 PUSH SW NPS-111-S681 1 25035718
PCB1
S828 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S829 PUSH SW NPS-111-S681 1 25035718
PCB1
S829 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S831 PUSH SW NPS-111-S681 1 25035718
PCB1
S831 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S832 PUSH SW NPS-111-S681 1 25035718
PCB1
S832 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S833 PUSH SW NPS-111-S681 1 25035718
PCB1
S833 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S834 PUSH SW NPS-111-S681 1 25035718
PCB1
S834 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S835 PUSH SW NPS-111-S681 1 25035718
PCB1
S835 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S836 PUSH SW NPS-111-S681 1 25035718
PCB1
S836 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S837 PUSH SW NPS-111-S681 1 25035718
PCB1
S837 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S838 PUSH SW NPS-111-S681 1 25035718
PCB1
S838 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S839 PUSH SW NPS-111-S681 1 25035718
PCB1
S839 or PUSH SW NPS-111-S677 (1) 25035714
PCB1
S851 R ENCODE EC12E2425 1 25065655
PCB1
P101A SOCKET NSCT-15P2108 1 25052211
PCB1
P132 PIN JACK NPJ-1PDBL291 1 25045473
PCB1
P132 or PIN JACK NPJ-1PDO554 (1) 25045772
PCB1
P301A SOCKET NSCT-10P2190 1 25052293
PCB1
P302A SOCKET NSCT-20P2200 1 25052303
PCB1
P303A SOCKET NSCT-20P2200 1 25052303
