Onkyo HT-R640 - Page 82

TX-SR604/604E/8460
IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS -45
Q8404,Q8602 : XC6213B332MR (Regulator with high-speed ON/OFF switch)
BLOCK DIAGRAM
INPUT
GND
ON/OFF CONTROL PIN
NOT USED
OUTPUT
PIN NO
PIN NAME
FUNCTION
PIN CONFIGURATION
TERMINAL DESCRIPTION
1
2
3
4
5
VIN
VSS
CE
NC
VOUT
