Onkyo HT-R8230 - Printed Circuit Board Parts List

3/30PAGE
EXPLODED
Q6063 or TR MP130S-P ( 1) 2203676
EXPLODED
Q6063 or TR MP130S-O ( 1) 2203673
EXPLODED
Q6063 or TR 2SA1962-O ( 1) 2202833
EXPLODED
Q6063 or TR 2SA1962-R ( 1) 2202832
EXPLODED
Q6064 TR MP130S-Y 1 2203674
EXPLODED
Q6064 or TR MP130S-P ( 1) 2203676
EXPLODED
Q6064 or TR MP130S-O ( 1) 2203673
EXPLODED
Q6064 or TR 2SA1962-O ( 1) 2202833
EXPLODED
Q6064 or TR 2SA1962-R ( 1) 2202832
EXPLODED
T901 P TRANS NPT-1491D 1 2301738
!
EXPLODED
U01 PREAMPLIFIER PCB ASSY NADG-7401-3E 1 1A978501-3E
EXPLODED
U02 DISPLAY PCB ASSY NADIS-7403-3B 1 1A978503-3B
EXPLODED
U03 SWITCH PCB ASSY NASW-7404-3B 1 1A978504-3B
EXPLODED
U04 HEADPHONE JACK PCB ASSY NAETC-7405-3B 1 1A978505-3B
EXPLODED
U08 DRIVER AMPLIFIER PCB ASSY NAAF-7866-3A 1 1A978566-3A
EXPLODED
U09 VIDEO & OPT TERMINAL PCB ASSYNAVD-7867-3A 1 1A978567-3A
EXPLODED
U10 REGULATOR PCB ASSY NAETC-7868-3A 1 1A978568-3A
EXPLODED
U11 TERMINAL PCB ASSY NAETC-7869-3A 1 1A978569-3A
EXPLODED
U12 SPEAKER TERMINAL PCB ASSY NAETC-7870-3A 1 1A978570-3A
EXPLODED
U17 POWER AMPLIFIER PCB ASSY NAAF-7875-2B 1 1A978575-2B
EXPLODED
U18 TERMINAL PCB ASSY NAPS-7876-2B 1 1A978576-2B
EXPLODED
U19 POWER SUPPLY PCB ASSY NAPS-7877-2B 1 1A978577-2B
EXPLODED
U20 TERMINAL PCB ASSY NAPS-7878-2B 1 1A978578-2B
EXPLODED
U23 HOLDER PCB ASSY NAETC-7881-2B 1 1A978581-2B
EXPLODED
U25 TERMINAL PCB ASSY NAETC-7884-2B 1 1A978584-2B
EXPLODED
U26 THERMAL SENSOR PCB ASSY NAETC-7856-2B 1 1A978556-2B
EXPLODED
U27 TUNER UNIT TFCE1U114B 1 240134A
EXPLODED
U27 or TUNER UNIT FAE385-A02F ( 1) 240146
EXPLODED
U27 or TUNER UNIT ENG06501QR ( 1) 240138A
EXPLODED
<Notes>
EXPLODED
When replacement the following the transistor,made from the same HFE rank as the original type.
EXPLODED
Q6050 - Q6054, Q6060 - Q6064
HTR-8230
PRINTED CIRCUIT BOARD PARTS LIS
T
U1
PREAMPLIFIER PC BOARD (NADG-7401-3E)
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
PWB
Q301 IC BD3811K1 1 22241761R3
PWB
Q302 IC NJM4565M-D 1 22241383R2
PWB
Q302 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PWB
Q302 or IC NJM4565M ( 1) 22240581R2
PWB
Q305 IC NJM4565M-D 1 22241383R2
PWB
Q305 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PWB
Q305 or IC NJM4565M ( 1) 22240581R2
PWB
Q306 TR RN2402 1 2214530R2
PWB
Q306 or TR KRA102S ( 1) 2216220R2
PWB
Q307 TR RN1441 1 2215410R2
PWB
Q308 TR RN1441 1 2215410R2
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
