Onkyo HT-R997 User Manual

12
4. Connect the Audio Component
Example of a connection with an audio component.
Connect a CD player using a digital optical cable or analog
audio cable. You can also connect a turntable that has an
MM-type cartridge to the PHONO jack.
0 If the turntable has a built-in audio equalizer, connect it to
another AUDIO IN jack. Further, if the turntable uses an
MC type cartridge, install an audio equalizer compatible
with the MC type cartridge between the unit and the
turntable, then connect to any AUDIO IN jack other than
the PHONO jack.
If the turntable has a ground wire,
connect it to the GND terminal of this unit.
> Before Start > Part Names >Install > Initial Setup > Playback
OR
CD
a
b
Turntable
a Digital optical cable, b Analog audio cable
SN29402830_HT-R997_BAS_En_1703XX.book 12 ページ ２０１７年３月１７日 金曜日 午前９時１８分

Onkyo HT-R997 Specifications

General

Audio output channels	7.1 channels
Audio formats supported	AIFF, ALAC, FLAC, WAV
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	580 W
Subwoofer frequency range	20 - 100 Hz
Center speaker sensitivity	83 dB
Satellite speaker sensitivity	81 dB
Package weight	63000 g
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
HDMI in	7
Component video (YPbPr/YCbCr) in	2
Disc types supported	No
Optical disc player type	Not included

Weight and Dimensions

Main unit weight	10000 g
Subwoofer weight	15500 g
Satellite speaker weight	3500 g
Main unit dimensions (WxDxH)	435 x 378 x 173.5 mm
Subwoofer dimensions (WxDxH)	380 x 429 x 444 mm
Front speaker dimensions (WxDxH)	158 x 199 x 433 mm
Center speaker dimensions (WxDxH)	433 x 199 x 158 mm
Satellite speaker dimensions (WxDxH)	200 x 169 x 275 mm
