L8301 CORE BLM18PG181SN1D 1 2350005R1
L8401 CORE BLM18PG181SN1D 1 2350005R1
L8402 CORE BLM18PG181SN1D 1 2350005R1
L8403 CORE BLM18PG181SN1D 1 2350005R1
L8404 CORE BLM18PG181SN1D 1 2350005R1
L8406 C-R NET MNR12E0APJ000 1 43464900002R2
L8407 C-R NET MNR12E0APJ000 1 43464900002R2
L8409 C-R NET MNR12E0APJ000 1 43464900002R2
L8410 C-R NET MNR12E0APJ000 1 43464900002R2
L8501 CORE BLM18PG181SN1D 1 2350005R1
L8502 CORE BLM18PG181SN1D 1 2350005R1
L8503 CORE BLM18PG181SN1D 1 2350005R1
L8504 CORE BLM18PG181SN1D 1 2350005R1
L8505 CORE BLM18PG181SN1D 1 2350005R1
L8506 CORE BLM18PG181SN1D 1 2350005R1
L8561 CORE BLM18PG181SN1D 1 2350005R1
L8608 EMIFIL BK1608LM182-T 1 230958R1
L8661 CORE BLM18PG181SN1D 1 2350005R1 <B MDC>
L8701 CORE BLM18PG181SN1D 1 2350005R1
L8801 CORE BLM18PG181SN1D 1 2350005R1
L8901 CHOKE COIL BLM21PG221SN1 1 230949R2
L8951 CHOKE COIL BLM21PG221SN1 1 230949R2
L8952 CHOKE COIL 0182-7E08Q-100M-RA 1 231396M100R2
L8953 CHOKE COIL BLM21PG221SN1 1 230949R2
L8954 CHOKE COIL BLM21PG221SN1 1 230949R2
L8955 CORE BLM18PG181SN1D 1 2350005R1
L8961 CHOKE COIL BLM21PG221SN1 1 230949R2
L8962 CHOKE COIL 0182-7E08Q-100M-RA 1 231396M100R2
L8963 CHOKE COIL BLM21PG221SN1 1 230949R2
L8964 CHOKE COIL BLM21PG221SN1 1 230949R2
X201 CRYSTAL HC-49USSMD17.734MHz 1 3010488R2 N
X8200 CRYSTAL HC-49USSMD19.6608MHz 1 3010489R2 N
X8501 CRYSTAL DSX321G-27MHz 1 3010487R2 N
X8701 CERA LOCK CSTCR5M00G53-B0 1 3010356R2
[CAPACITOR]
C201 C-CERA C CK725F1E-104Z1 1 332161040R1 NSP
C202 C-CERA C CK725B1H-102K1 1 332101025R1 NSP
C203 C-CERA C CK725F1E-104Z1 1 332161040R1 NSP
C204 C-CERA C CK725B1H-102K1 1 332101025R1 NSP
C205 C-CERA C CK725F1E-104Z1 1 332161040R1 NSP
C206 C-CERA C CK725B1H-102K1 1 332101025R1 NSP
C207 C-CERA C CK725F1E-104Z1 1 332161040R1 NSP
C208 C-CERA C CK725B1H-102K1 1 332101025R1 NSP
