Onkyo HT-RC260 Service Manual

R810 C-CARBON R RN72K1J-000JE 1 435030004R1 NSP <B MDC>
R822 C-CARBON R RN72K1J-000JE 1 435030004R1 NSP <B MDC>
[SW TRM]
JL501B WIRE TRAP NPLG-3P586 1 25055624
JL502B WIRE TRAP NPLG-5P588 1 25055626
JL610B WIRE TRAP NPLG-7P590 1 25055628 <B MDC>
JL901B WIRE TRAP NPLG-5P588 1 25055626
P101A SOCKET NSCT-11P2104 1 25052207 <B MDC>
P131 PIN JACK NPJ-2PDOO626 1 25045847 <B MDC>
P131 or PIN JACK NPJ-2PDO445 ( 1) 25045640 <B MDC>
P2001A SOCKET IMSA-9142S-24A 1 25053234
P2002B SOCKET NSCT-15P2195 1 25052298
P2081 SOCKET NNA1-01-006 1 25053357
P5501A SOCKET NSCT-7P2187 1 25052290
P5502A SOCKET NSCT-15P2195 1 25052298
P5503A SOCKET NSCT-9P2189 1 25052292
P5504A SOCKET NSCT-7P2187 1 25052290 <B MDC>
P701A SOCKET NSCT-31P2124 1 25052227
P751A SOCKET IMSA-9618S-09A 1 25053334R2
P8001A PLUG IMSA-9111B-16 1 25056620
P8002A PLUG IMSA-9111B-24 1 25056625
[TUNER UNIT]
U131 PHT CP JSR1165-001recieving 1 24120143
U132 PHT CP JSR1165-001recieving 1 24120143
HT-RC260
PC BOARD PARTS LIS
T
U004
DIS-
AS（Display Asy)
U0040+U0041+U0042+U004
3+U0044
BADIS-0373-1M * 1 1B247573-1M N <B MDC>
U0040
DIS-AS（Dis
p
la
y
A
s
y)
BADIS-0373-1M 1 1B2475373-1M N <B MDC>
U0041
PWB（Standb
y
ke
y
/LED
A
s
y)
BADIS-0374-1M 1 Included in "REF, NO, U0040 N <B MDC>
U0042
PWB（Video As
y)
BAVD-0375-1M 1 1B2475375-1M N <B MDC>
U0043
PWB
(
Power Su
pp
l
y
As
y)
BAETC-0376-1M 1 1B2475376-1M N <B MDC>
U0044
PWB
(
HP Jack
)
BAETC-0377-1M 1 1B2475377-1M N <B MDC>
CIRCUIT PART NAME DESCRIPTION
Q
'T
Y
PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D7002 ZENER D UDZS8.2B 1 224550820R2
D7033 ZENER D UDZS3.9B 1 224550390R2
D7151 LED SLI-343URC-TE7 1 225449T
D7152 LED SLI-343Y8C-TE7 1 225490T N
D7153 LED SLR-342MGTE7P 1 225455T <B MDC>
