Onkyo HT-RC260 Service Manual

A861 BATTERY R6/AA(UM-3) 2 3010194 <B MDC>
A861 or BATTERY R6/AA(UM-3) ( 2) 3010054 <B MDC>
A885 WRNTY CARD (ONKYO) 1 29365135 <B MDC>
HT-RC260
PC BOARD PARTS LIS
T
U001
A
F-AS(Amplifier Asy)
U0010+U0011+U0012+U0013+U0014
BAAF-0355-1E * 1 1B247555-1E N <B MDC>
U0010
A
F-AS
(
Am
p
lifier As
y)
BAAF-0355-1E 1 1B2475355-1E N <B MDC>
U0011 PWB
(
FL Tube -VP
)
BAPS-0356-1E 1 1B2475356-1E N <B MDC>
U0012
PWB
(
Themal Sensor
)
BAETC-0357-1E 1 1B2475357-1E N <B MDC>
U0013
PWB
(
Themal Sensor FIX
)
BAETC-0358-1E 1 1B2475358-1E N, NSP <B MDC>
U0014
PWB
(
Trans Terminal FIX
)
BAETC-0359-1E 1 1B2475359-1E N <B MDC>
CIRCUIT PART NAME DESCRIPTION
Q
'T
Y
PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4171 ZENER D MTZJ7.5B 1 224470752T
D4172 ZENER D MTZJ7.5B 1 224470752T
D4207 C-DIODE KDS4148U 1 223283R2 NSP <B MDC>
D4207 or C-DIODE 1SS352 ( 1) 223234R2 NSP <B MDC>
D4207 or C-DIODE MA2J111 ( 1) 223279R2 NSP <B MDC>
D4217 C-DIODE KDS4148U 1 223283R2 NSP <B MDC>
D4217 or C-DIODE 1SS352 ( 1) 223234R2 NSP <B MDC>
D4217 or C-DIODE MA2J111 ( 1) 223279R2 NSP <B MDC>
D4300 DIODE RL1N4003 1 22380260T
D4301 DIODE RL1N4003 1 22380260T
D4302 DIODE RL1N4003 1 22380260T
D4303 DIODE RL1N4003 1 22380260T
D4304 DIODE RL1N4003 1 22380260T
D4305 DIODE RL1N4003 1 22380260T
D6000 C-DIODE KDS4148U 1 223283R2 NSP
D6000 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D6000 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D6001 C-DIODE KDS4148U 1 223283R2 NSP
D6001 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D6001 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D6002 C-DIODE KDS4148U 1 223283R2 NSP
D6002 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D6002 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D6003 C-DIODE KDS4148U 1 223283R2 NSP
D6003 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D6003 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D6004 C-DIODE KDS4148U 1 223283R2 NSP
D6004 or C-DIODE 1SS352 ( 1) 223234R2 NSP
