U0041
PWB（Standb
y
ke
y
/LED
A
s
y)
BADIS-0374-1M 1 Included in "REF, NO, U0040 N <B MDC>
U0042
PWB（Video As
y)
BAVD-0375-1M 1 1B2475375-1M N <B MDC>
U0043
PWB
(
Power Su
pp
l
y
As
y)
BAETC-0376-1M 1 1B2475376-1M N <B MDC>
U0044
PWB
(
HP Jack
)
BAETC-0377-1M 1 1B2475377-1M N <B MDC>
U006
TRM-AS(SP Terminal Asy)
U0060+U0061+U0062+U0063
BATRM-0368-1J * 1 1B247568-1J N <B MDC>
U0060
TRM-AS
(
SP Terminal As
y)
BATRM-0368-1J 1 1B2475368-1J N <B MDC>
U0063
PWB
(
D SUB
)
BAETC-0371-1J 1 1B2475371-1J N <B MDC>
U0064
PWB
(
etc reserve
)
BAETC-0372-1J 1 1B2475372-1J N, NSP <B MDC>
U007
HDM-AS(HDMI Asy)
U0070+U0071+U0072
BAHDM-0403-1E * 1 1B247503-1E N <B MDC>
U0070
HDM-AS
(
HDMI As
y)
BAHDM-0403-1E 1 1B2475403-1E N <B MDC>
U0071
PWB
(
Front HDMI As
y)
BAHDM-0404-1E 1 1B2475404-1E N <B MDC>
U0072
PWB
(
Front HDMI As
y
FIX
)
BAETC-0405-1E 1 1B2475405-1E N, NSP <B MDC>
U010 TUNER UNIT FAEH06-A01US 1 240166 <B MDC>
HT-RC260
PACKING PROCEDURES PARTS LIS
T
REF. NO PART NAME DESCRIPTION
Q
'T
Y
PART NO. (SN) REMARKS
[PACKING]
A601 PAD (AS)608 1 29092500 <B>
A605 POLY BAG w850xd650 1 29100245 <B>
A606 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A610 SHEET (PAD) 1 29096095 <B>
A611 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A700 PP TAPE W50 SBT-70 1 29110200 <B MDC>
A701 CARTON 260DC 1 29055101 N <B MDC>
A704A UPC LABEL 260BMDC { 1} 29391079 N <B MDC>
A760 PP TAPE W50 SBT-70 1 29110200 <B>
[ACCESSARY]
A674 POLY BAG D250xd300xW300(t0.04) 1 29100256A <B>
A676 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A801 INS MANUAL En(HT-RC260) 1 29400276 N <B>
A802 INS MANUAL U2FrEs(HT-RC260) 1 29400277 N <B MDC>
A810 INS MANUAL En(QSS HT-RC260) 1 29400280 N <B>
A823 INS MANUAL U9(2010_Prepro) 1 29400269 <B>
A826 INST SHEET U11(2010_RIHD) 1 29355782 <B>
A835 HANDBILL (UP-A1)US 1 29380155A <B MDC>
A855 REMO CON RC-764M 1 24140764 <B>
A856 MIC MIC-7000 1 245044 <B>
A858 ANT COIL NMA-3057 1 232140 <B>
A859 FM ANT AS Type W 1 292191 <B>
A860 LABEL (SPCABLE)2009 1 29390881 <B>
