C5020 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
C5021 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
C5022 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
C5023 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
C5024 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
C5040 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C5041 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C5042 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C5043 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C5044 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-220M(UTSP) 1 397552217T
C5050 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C5051 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C5052 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C5053 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C5054 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
1
C5080 CERAMIC CAPACITOR CC45SL50V-040C 1 345020401T
1
C5081 CERAMIC CAPACITOR CC45SL50V-040C 1 345020401T
1
C5082 CERAMIC CAPACITOR CC45SL50V-040C 1 345020401T
1
C5083 CERAMIC CAPACITOR CC45SL50V-040C 1 345020401T
1
C5084 CERAMIC CAPACITOR CC45SL50V-040C 1 345020401T
1
C5090 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF101JE 1 376331014T
1
C5091 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF101JE 1 376331014T
1
C5092 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF101JE 1 376331014T
1
C5093 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF101JE 1 376331014T
1
C5094 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF101JE 1 376331014T
C5100 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5101 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5102 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5103 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5104 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5110 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5111 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5112 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5113 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C5114 VR TYPE ELECTROLYTIC CAPACITOR CE04W100V-22M(VR) 1 394692207T
C6040 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C6041 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C6042 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C6043 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
C6044 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 1 397584707AT
[RESISTOR]
1
R5000 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R5001 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R5002 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R5003 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R5004 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R5010 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 1 435035634R1
1
R5011 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 1 435035634R1
1
R5012 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 1 435035634R1
1
R5013 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 1 435035634R1
1
R5014 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 1 435035634R1
1
R5020 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R5021 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R5022 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R5023 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R5024 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
R5030 NON-FLAMMABLE CARBON FILM RESISTOR R25J-56K 1 415475634T
R5031 NON-FLAMMABLE CARBON FILM RESISTOR R25J-56K 1 415475634T
R5032 NON-FLAMMABLE CARBON FILM RESISTOR R25J-56K 1 415475634T
R5033 NON-FLAMMABLE CARBON FILM RESISTOR R25J-56K 1 415475634T
R5034 NON-FLAMMABLE CARBON FILM RESISTOR R25J-56K 1 415475634T
1
R5040 CHIP TYPE CARBON RESISTOR RN72K1J-182JE 1 435031824R1

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
