1/38 PAGE

HT-RC630(B)MDC

<Note>

Parts marked by "NSP" are generally unavailable because

<Notes>

they are not in our Master Spare Parts List.

(B) : Black color model

<MDC> : 120V

Canadian/USA/(Mexico) model

: NSP

HT-RC630(B)MDC

EXPLODED VIEW PARTS LIST

REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS

[SEMI CONDUCTOR]

Q6050 TRANSISTOR 2SC5198-O 1 2203063

Q6050 or TRANSISTOR 2SC4468-O ( 1) 2202523

Q6050 or TRANSISTOR 2SC4468-P ( 1) 2202526

Q6050 or TRANSISTOR 2SC5198-R ( 1) 2203062

Q6051 TRANSISTOR 2SC5198-O 1 2203063

Q6051 or TRANSISTOR 2SC4468-O ( 1) 2202523

Q6051 or TRANSISTOR 2SC4468-P ( 1) 2202526

Q6051 or TRANSISTOR 2SC5198-R ( 1) 2203062

Q6052 TRANSISTOR 2SC5198-O 1 2203063

Q6052 or TRANSISTOR 2SC4468-O ( 1) 2202523

Q6052 or TRANSISTOR 2SC4468-P ( 1) 2202526

Q6052 or TRANSISTOR 2SC5198-R ( 1) 2203062

Q6053 TRANSISTOR 2SC5198-O 1 2203063

Q6053 or TRANSISTOR 2SC4468-O ( 1) 2202523

Q6053 or TRANSISTOR 2SC4468-P ( 1) 2202526

Q6053 or TRANSISTOR 2SC5198-R ( 1) 2203062

Q6054 TRANSISTOR 2SC5198-O 1 2203063

Q6054 or TRANSISTOR 2SC4468-O ( 1) 2202523

Q6054 or TRANSISTOR 2SC4468-P ( 1) 2202526

Q6054 or TRANSISTOR 2SC5198-R ( 1) 2203062

Q6060 TRANSISTOR 2SA1941-O 1 2203053

Q6060 or TRANSISTOR 2SA1695-O ( 1) 2202513

Q6060 or TRANSISTOR 2SA1695-P ( 1) 2202516

Q6060 or TRANSISTOR 2SA1941-R ( 1) 2203052

Q6061 TRANSISTOR 2SA1941-O 1 2203053

Q6061 or TRANSISTOR 2SA1695-O ( 1) 2202513

Q6061 or TRANSISTOR 2SA1695-P ( 1) 2202516

Q6061 or TRANSISTOR 2SA1941-R ( 1) 2203052

Q6062 TRANSISTOR 2SA1941-O 1 2203053

Q6062 or TRANSISTOR 2SA1695-O ( 1) 2202513

Q6062 or TRANSISTOR 2SA1695-P ( 1) 2202516

Q6062 or TRANSISTOR 2SA1941-R ( 1) 2203052

Q6063 TRANSISTOR 2SA1941-O 1 2203053

Q6063 or TRANSISTOR 2SA1695-O ( 1) 2202513

Q6063 or TRANSISTOR 2SA1695-P ( 1) 2202516

Q6063 or TRANSISTOR 2SA1941-R ( 1) 2203052

Q6064 TRANSISTOR 2SA1941-O 1 2203053

Q6064 or TRANSISTOR 2SA1695-O ( 1) 2202513

Q6064 or TRANSISTOR 2SA1695-P ( 1) 2202516

Q6064 or TRANSISTOR 2SA1941-R ( 1) 2203052

[CHASSIS SCREW]

A003 BOTTOM LEG phi48(313) 4 27175472

A005 CUSHION (ZUL) phi20 x phi8 4 28141900

A101 REAR PANEL HTRC630MDC 1 27124609A

[CABINET]

A201 FRONT PANEL HTRC630(B)DC/PP 1 27213733

A203 CLEAR PLATE 333(B)D 1 28192436

A205 BADGE 1 28135317

NOTE : THE COMPONENTS IDENTIFIED BY THE MARK

! ARE CRITICAL FOR RISK OF FIRE AND

ELECTRIC SHOCK. REPLACE ONLY WITH

PART
