2/38 PAGE
A207 KNOB (TONE)(B) 1 28326912
A209 KNOB (INP)B_535 1 28327172A
A211 KNOB (SEL) 1 28326906B
A213 KNOB (INP-L)B_535 1 28327174C
A214 KNOB (INP-R)B_535 1 28327175C
A215 FACET (KNOB)_535 2 28200076
A217 KNOB (STBY)(B) 1 28326904
A219 KNOB (CUR) 1 28326907B
A221 KNOB (VOL)AS(B) 1 28326933
A401 COVER (B) (Bent) 1 28210089A
A401 COVER (B) (Not Bent) 1 28210089AZ
A411 LABEL (CAUTION) 1 29392531
[TRANS COIL]
T901 POWER TRANSFORMER NPT-1639D 1 2302088
!
[SW TRM]
F6401 FUSE 10A-UL/T-233 1 252330GR
!
F6401 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
F6402 FUSE 10A-UL/T-233 1 252330GR
!
F6402 or FUSE 10A-T/UL-ST2 ( 1) 252333GR
!
F901 FUSE 6A-UL/T-233 1 252327GR
!
P101 FLEXIBLE FLAT CABLE NCFC7-071012 1 2047071012
P2800 FLEXIBLE FLAT CABLE NCFC5-131012 1 2045131012
P701 FLEXIBLE FLAT CABLE NCFC5-232512 1 2045232512
P8001 FLEXIBLE FLAT CABLE NCFC5-211012 1 2045211012
P8003 FLEXIBLE FLAT CABLE NCFC5-090512 1 2045090512
P801 FLEXIBLE FLAT CABLE NCFC5-071012 1 2045071012
P9001 POWER SUPPLY CORD AS-UC-2 1 253368AYUN
!
P9001 or POWER SUPPLY CORD AS-UC-2 ( 1) 253368BLTK
!
[TUNER UNIT]
U001 U0010, U0011, U0012, U0013 BAAF-1672-1A * (Parent) 1 1B299572-1A MDC
U0010 AMP/ ASP PC BOARDS AS BAAF-1672-1A (Child) 1 1B2995672-1A
U0011 SENSOR(THERMAL) PC BOARDS AS BAETC-1673-1A (Child) 1 1B2995673-1A
U0012 FIX(THERMAL) PC BOARDS AS BAETC-1674-1A (Child) 1 1B2995674-1A
U0013 TERMINAL(DIGITAL) PC BOARDS AS BADG-1664-1A (Child) 1 1B2995664-1A
U003 U0030, U0031, U0032 x 2 pcs. BACLA-1522-2A * (Parent) 1 1B299522-2A MDC
U0030 AMP(CLASS-A) PC BOARDS AS BACLA-1522-2A (Child) 1 1B2995522-2A
U0031 FIX(FFC) PC BOARDS AS BAETC-1523-2A (Child) 1 1B2995523-2A
U0032 FIX(HP CABLE) PC BOARDS AS BAETC-1528-2A (Child) 1 1B2995528-2A
U004 U0040, U0041, U0042, U0043, U0044, U0045 BADIS-1658-1A * (Parent) 1 1B299558-1A MDC
U0040 DISPLAY PC BOARDS AS BADIS-1658-1A (Child) 1 1B2995658-1A
U0041 KEY /LED PC BOARDS AS BASW-1659-1A (Child) 1 1B2995659-1A
U0042 TERMINAL PC BOARDS AS BAETC-1660-1A (Child) 1 1B2995660-1A
U0043 VIDEO PC BOARDS AS BAVD-1661-1A (Child) 1 1B2995661-1A
U0044 PHONE JACK PC BOARDS AS BAETC-1662-1A (Child) 1 1B2995662-1A
U0045 POWER SUPPLY(PRI) PC BOARDS AS BAPS-1663-1A (Child) 1 1B2995663-1A
U008 U0080 x 2 pcs. BAPRC-1670-1A * (Parent) 1 1670-1A_HTRC630MDC MDC
U0080 PROCESSING PC BOARDS AS BAPRC-1670-1A (Child) 1 1B2995670-1A_RC630DC
U009 U0090 x 25 pcs. BARF-1567-3A * (Parent) 1 1B299567-3A MDC
U0090 CONNCTOR(Wifi)/ BPF PC BOARDS AS BARF-1567-3A (Child) 1 1B2995567-3A
U012 U0120 x 25 pcs. BARF-1450-3A * (Parent) 1 1B299550-3A MDC
U0120 TUNER PC BOARDS AS BARF-1450-3A (Child) 1 1B2995450-3A
U0120A SHIELD CASE (TUNER-TOP) 1 27225206A
U0120B SHIELD CASE (TUNER-BTM) 1 27225207A
U791 WIFI MODULE(U791A+U791B+U791C) WCBN4601L-O1(wANT_IN) 1 24850701
U791A ASSEMBLED PWB WCBN4601L-O1 { 1} 24150122
U791B WIFI BT ANTENA 2.4GHZ ANT L1 { 1} 2050091
U791C WIFI BT ANTENA 2.4GHZ ANT R1 { 1} 2050092

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
