Onkyo HT-RC630 User Manual

19/38 PAGE
F201 FUSE T4A-SEUL-T250V 1 252392T
!
1
R2001 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 1 435035634R1
1
R2002 CHIP TYPE CARBON RESISTOR RN72K1J-563JE 1 435035634R1
1
R2007 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R2008 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R201 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R202 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R205 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R2051 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2101 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2102 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2103 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2106 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2107 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2108 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2109 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2110 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2111 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2112 CHIP TYPE CARBON RESISTOR RN72K1J-750JE 1 435037504R1
1
R2114 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R2115 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R2116 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R2117 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R7001 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7002 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R7003 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R7004 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R7005 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R7006 CHIP TYPE CARBON RESISTOR RN72K1J-332JE 1 435033324R1
1
R7007 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R7008 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R7009 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7010 CHIP TYPE CARBON RESISTOR RN72K1J-333JE 1 435033334R1
1
R7011 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R7012 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7013 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7014 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 1 435031524R1
1
R7021 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7022 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7023 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7024 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R7033 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R7041 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
1
R7042 CHIP TYPE CARBON RESISTOR RN72K1J-102JE 1 435031024R1
1
R7101 CHIP TYPE CARBON RESISTOR RN72K1J-271JE 1 435032714R1
1
R7102 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R7103 CHIP TYPE CARBON RESISTOR RN72K1J-471JE 1 435034714R1
1
R7104 CHIP TYPE CARBON RESISTOR RN72K1J-561JE 1 435035614R1
1
R7105 CHIP TYPE CARBON RESISTOR RN72K1J-821JE 1 435038214R1
1
R7106 CHIP TYPE CARBON RESISTOR RN72K1J-122JE 1 435031224R1
1
R7107 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R7108 CHIP TYPE CARBON RESISTOR RN72K1J-392JE 1 435033924R1
1
R7109 CHIP TYPE CARBON RESISTOR RN72K1J-123JE 1 435031234R1
1
R7111 CHIP TYPE CARBON RESISTOR RN72K1J-271JE 1 435032714R1
1
R7112 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 1 435033314R1
1
R7113 CHIP TYPE CARBON RESISTOR RN72K1J-471JE 1 435034714R1
1
R7114 CHIP TYPE CARBON RESISTOR RN72K1J-561JE 1 435035614R1
1
R7115 CHIP TYPE CARBON RESISTOR RN72K1J-821JE 1 435038214R1
1
R7116 CHIP TYPE CARBON RESISTOR RN72K1J-122JE 1 435031224R1
1
R7117 CHIP TYPE CARBON RESISTOR RN72K1J-222JE 1 435032224R1
1
R7118 CHIP TYPE CARBON RESISTOR RN72K1J-392JE 1 435033924R1
1
R7119 CHIP TYPE CARBON RESISTOR RN72K1J-123JE 1 435031234R1

Onkyo HT-RC630 Specifications

General

Output level	100 mV
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Dynamic power per channel (3 Ohm)	160 W
Dynamic power per channel (4 Ohm)	125 W
Dynamic power per channel (8 Ohm)	85 W
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	6
Audio (L/R) in	7
Composite video in	4
Digital audio coaxial in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Damping factor	60
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Package weight	10500 g

Weight and Dimensions

Depth	321 mm
Width	435 mm
Height	150 mm
Weight	8100 g
