Onkyo HT-S5800 User Manual

2/39 PAGE
Q6066 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6066 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6066 or TRANSISTOR 2SA1941-R ( 1) 2203052
[CHASSIS SCREW]
A002 BOTTOM LEG phi48(313) 4 27175472
A003 CUSHION (ZUL) phi20 x phi8 4 28141900
A101 REAR PANEL HTR494MDC 1 27124643A N
[CABINET]
A201 FRONT PANEL HTR494(B) 1 27213762 N
A202 CLEAR PLATE HTR494(B)MDC 1 28192447
A203 BADGE LABEL 1 28135323 N
A204 KNOB (TONE)TXSR343(B)_3 1 28327200
A205 KNOB (MU)TXSR343(B)_1 1 28327202
A206 KNOB (INP)TXSR343(B) 1 28327194
A207 KNOB (SEL)TXSR343(B) 1 28327196A N
A208 KNOB (MODE)TXSR343(B) 1 28327198A
A209 KNOB (STBY)(B) 1 28327234
A209 or KNOB (STBY)(B) ( 1) 28326904
A210 KNOB (CUR) 1 28326907B
A211 KNOB (VOL)AS_TXSR343(B) 1 28327192
A401 COVER 343/444(B) (Bent) 1 28210142A
A401 COVER 343/444(B) (Not Bent) 1 28210142AZ
A403 LABEL (CAUTION) 1 29392531
[TRANS COIL]
T901 POWER TRANSFORMER NPT-1656D 1 2302131 !
[SW TRM]
F6401 FUSE 10A-UL/T-233 1 252330GR !
F6401 or FUSE 10A-T/UL-ST2 ( 1) 252333GR !
F6402 FUSE 10A-UL/T-233 1 252330GR !
F6402 or FUSE 10A-T/UL-ST2 ( 1) 252333GR !
F9001 FUSE 8A-UL/T-233 1 252329GR !
F9001E LABEL 8A/125V 1 29360842
P101 FLEXIBLE FLAT CABLE NCFC7-071012 1 2047071012
P2800 FLEXIBLE FLAT CABLE NCFC5-231012 1 2045231012
P7001 FLEXIBLE FLAT CABLE NCFC5-232512 1 2045232512
P8001 FLEXIBLE FLAT CABLE NCFC5-231012 1 2045231012
P8002 FLEXIBLE FLAT CABLE NCFC5-171012 1 2045171012
P9001 POWER SUPPLY CORD AS-UC-2 1 253368AYUN !
P9001 or POWER SUPPLY CORD AS-UC-2 ( 1) 253368BLTK !
[TUNER UNIT]
U001 PARENT PC BOARD AS BAAF-1712-1G * (Parent) 1 1B303512-1G MDC
BAAF-1712 ASP/ AMP PC BOARD AS BAAF-1712-1G (Child) 1 1B3035712-1G
BAETC-1713
THERMAL SENSOR PC BOARD AS BAETC-1713-1G (Child) 1 1B3035713-1G
BAETC-1714
SPASER(SENSOR) PC BOARD AS BAETC-1714-1G (Child) 1 1B3035714-1G
BAETC-1715
PHONE JACK PC BOARD AS BAETC-1715-1G (Child) 1 1B3035715-1G
U002 PARENT PC BOARD AS BADIS-1732-1A * (Parent) 1 1B303532-1A MDC
BADIS-1732 DISPLAY PC BOARD AS BADIS-1732-1A (Child) 1 1B3035732-1A
BACLA-1734
VOLTAGE AMP PC BOARD AS BACLA-1734-1A (Child) 1 1B3035734-1A
BAVD-1735 VIDEO/ OPT TERMINAL PC BOARD AS BAVD-1735-1A (Child) 1 1B3035735-1A
BAETC-1736
HOLDER PC BOARD AS BAETC-1736-1A (Child) 1 1B3035736-1A
BAPS-1737 POWER SUPPLY(PRI) PC BOARD AS BAPS-1737-1A (Child) 1 1B3035737-1A
BARF-1738 TUNER PC BOARD AS BARF-1738-1A (Child) 1 1B3035738-1A
U004 PARENT PC BOARD AS BAPRC-1758-1D * (Parent) 1 1B303558-1D MDC
BAPRC-1758
PROCESSOR PC BOARD AS BAPRC-1758-1D (Child) 1 1B3035758-1D
U005 PARENT PC BOARD AS BARF-1764-1A * (Parent) 1 1B303564-1A MDC
BARF-1764 BLUETOOTH MODULE PC BOARD AS BARF-1764-1A (Child) 1 1B3035764-1A
U002A SHIELD CASE (TUNER-TOP) 1 27225206A
U002B SHIELD CASE (TUNER-BTM) 1 27225207A
