10
> Before start > Hookup > Setup > Playback > Part Names > Advanced Manual
Troubleshooting | Appendix
For high-
frequency
For low-
frequency
1 Speaker cable
Connections with Bi-
Amping speakers
Connect front speakers compatible with Bi-Amping
connection to the FRONT jacks and the HEIGHT 1 jacks.
Make sure you remove the jumper bar fitted between the
woofer jacks and tweeter jacks of the front speakers. In
case of Bi-Amping connection, refer to the instruction
manual of your speakers.
Make sure the exposed wires of the speakers do not stick out of
the speaker terminals when connecting. If the exposed wires of
the speakers touch the rear panel or the + and – wires touch each
other, the protection circuit will be activated.
To Next Page
