R6046 TRIM R N06HR1KBB 1 5211401T
R6050 C-CARBON R RN72K1J-332JE 1 435033324R1
R6051 C-CARBON R RN72K1J-332JE 1 435033324R1
R6052 C-CARBON R RN72K1J-332JE 1 435033324R1
R6053 C-CARBON R RN72K1J-332JE 1 435033324R1
R6054 C-CARBON R RN72K1J-332JE 1 435033324R1
R6055 C-CARBON R RN72K1J-332JE 1 435033324R1
R6056 C-CARBON R RN72K1J-332JE 1 435033324R1
R6070 NF CARBON R R25J-100 1 415471014T
R6071 NF CARBON R R25J-100 1 415471014T
R6072 NF CARBON R R25J-100 1 415471014T
R6073 NF CARBON R R25J-120 1 415471214T
R6074 NF CARBON R R25J-120 1 415471214T
R6075 NF CARBON R R25J-120 1 415471214T
R6076 NF CARBON R R25J-120 1 415471214T
[SW TRM]
P5507B TRM NTM-1P233(M1969) 1 25060302
P5509B TRM NTM-1P233(M1969) 1 25060302
P6000 SOCKET NSCT-9P2189 1 25052292
P6001 SOCKET NSCT-9P2189 1 25052292
P6002 SOCKET NSCT-9P2189 1 25052292
P6003 SOCKET NSCT-9P2189 1 25052292
P6004 SOCKET NSCT-9P2189 1 25052292
P6005 SOCKET NSCT-9P2189 1 25052292
P6006 SOCKET NSCT-9P2189 1 25052292
U004 BATRM-1089-2C
: NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D1000 C-DIODE DA2J10100 1 223303R2
D1000 or C-DIODE 1SS352 ( 1) 223234R2
D1001 C-DIODE DA2J10100 1 223303R2
D1001 or C-DIODE 1SS352 ( 1) 223234R2
D6600 C-DIODE DA2J10100 1 223303R2
D6600 or C-DIODE 1SS352 ( 1) 223234R2
D6603 C-DIODE DA2J10100 1 223303R2
D6603 or C-DIODE 1SS352 ( 1) 223234R2
D6605 C-DIODE DA2J10100 1 223303R2
D6605 or C-DIODE 1SS352 ( 1) 223234R2
D6607 C-DIODE DA2J10100 1 223303R2
D6607 or C-DIODE 1SS352 ( 1) 223234R2
Q1000 IC TC74HCU04AF 1 222740046R2TO
Q6601 TR KRC105S 1 2217290R2
Q6602 TR KRC105S 1 2217290R2
Q6603 TR KRC105S 1 2217290R2
Q6604 TR KRC105S 1 2217290R2
[TRANS COIL]
L1000 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L1001 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L1002 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L1003 CHOKE COIL LBC2518T470M 1 231364M470R2
L1004 CHOKE COIL LBC2518T470M 1 231364M470R2
L1005 EMIFIL BK1608HS102-T 1 230955R2
L1006 EMIFIL BK1608HS102-T 1 230955R2
[CAPACITOR]
C1000 C-CERA C CK725F1E-104Z1 1 332161040R1
C1001 C-CERA C CC725CH1H-101J1 1 342101014R1
C1002 C-CERA C CC725CH1H-101J1 1 342101014R1
C1003 C-CERA C CK725B1C-104K1 1 332121045R1
C1004 C-CERA C CK725B1C-104K1 1 332121045R1
C1005 C-CERA C CC725CH1H-080D1 1 342100802R1
C1006 C-CERA C CC725CH1H-080D1 1 342100802R1
C1007 UTSP C CE04W10V-220M(UTSP) 1 397532217AT
C1008 C-CERA C CK725F1E-104Z1 1 332161040R1
C1009 C-CERA C CK725F1E-104Z1 1 332161040R1
C1011 C-CERA C CC725CH1H-330J1 1 342103304R1
C1013 UTSP C CE04W10V-220M(UTSP) 1 397532217AT
C6600 C-CERA C CC725CH1H-102J1 1 342101024R1
C6602 C-CERA C CC725CH1H-102J1 1 342101024R1
C6603 C-CERA C CC725CH1H-102J1 1 342101024R1
C6605 C-CERA C CC725CH1H-102J1 1 342101024R1
C6607 C-CERA C CC725CH1H-102J1 1 342101024R1
