[RESISTOR]
R1000 C-CARBON R RN72K1J-331JE 1 435033314R1
R1001 C-CARBON R RN72K1J-750JE 1 435037504R1
R1002 C-CARBON R RN72K1J-750JE 1 435037504R1
R1003 C-CARBON R RN72K1J-100JE 1 435031004R1
R1004 C-CARBON R RN72K1J-100JE 1 435031004R1
R1005 C-CARBON R RN72K1J-224JE 1 435032244R1
R1006 C-CARBON R RN72K1J-224JE 1 435032244R1
R1007 C-CARBON R RN72K1J-103JE 1 435031034R1
R1008 C-CARBON R RN72K1J-103JE 1 435031034R1
R1009 C-CARBON R RN72K1J-823JE 1 435038234R1
R1010 C-CARBON R RN72K1J-823JE 1 435038234R1
R1011 C-CARBON R RN72K1J-470JE 1 435034704R1
R6690 METAL O R RS1/2W BJ-10 1 443521004T
R6691 METAL O R RS1/2W BJ-390 1 443523914T
R6692 METAL O R RS1/2W BJ-390 1 443523914T
[SW TRM]
JL600B PLUG NPLG-7P121 1 25055137
JL603B PLUG NPLG-9P123 1 25055139
JL604B PLUG NPLG-5P119 1 25055135
JL605B PLUG NPLG-5P119 1 25055135
P1000 ST JACK MSJ-035-22 1 25045887
P1001 PIN JACK NPJ-2PDOO626 1 25045847
P6601 TRM NTM-2PDMCR400 1 25060472
P6602 TRM NTM-4PDMNRR420 1 25060492
P6603 TRM NTM-4PDMNRR420 1 25060492
P6604 TRM NTM-4PDMNRR420 1 25060492
P8003B PLUG NPLG-9P0964 1 25056014
P8004A SOCKET NSCT-7P2398 1 25052501
RL660 RELAY NRL-2P5A-DC24-129 1 25065563A
RL662 RELAY NRL-2P5A-DC24-129 1 25065563A
RL663 RELAY NRL-2P5A-DC24-129 1 25065563A
RL665 RELAY NRL-2P5A-DC24-129 1 25065563A
RL667 RELAY NRL-2P5A-DC24-129 1 25065563A
[TUNER UNIT]
U1001 PHT CP JSR1165-001recieving 1 24120143
U006 BADIS-1370-1C
: NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D7002 ZENER D DZ2J082M0L 1 224760820R2
D7002 or ZENER D UDZS8.2B ( 1) 224550820R2
D7033 ZENER D DZ2J039M0L 1 224760390R2
D7033 or ZENER D UDZS3.9B ( 1) 224550390R2
D7152 LED SLI-343Y8C-TE7 1 225490T
D7301 C-DIODE DA2J10100 1 223303R2
D7301 or C-DIODE 1SS352 ( 1) 223234R2
D7302 C-DIODE DA2J10100 1 223303R2
D7302 or C-DIODE 1SS352 ( 1) 223234R2
D7401 ZENER D DZ2J051M0L 1 224760510R2
D7401 or ZENER D UDZS5.1B ( 1) 224550510R2
D7411 ZENER D DZ2J068M0L 1 224760680R2
D7411 or ZENER D UDZS6.8B ( 1) 224550680R2
D7412 ZENER D DZ2J068M0L 1 224760680R2
D7412 or ZENER D UDZS6.8B ( 1) 224550680R2
D7501 C-DIODE DA2J10100 1 223303R2
D7501 or C-DIODE 1SS352 ( 1) 223234R2
D7502 C-DIODE DA2J10100 1 223303R2
D7502 or C-DIODE 1SS352 ( 1) 223234R2
D7503 C-DIODE DA2J10100 1 223303R2
D7503 or C-DIODE 1SS352 ( 1) 223234R2
D7504 C-DIODE DA2J10100 1 223303R2
D7504 or C-DIODE 1SS352 ( 1) 223234R2
D9011 DIODE D5SBA60 1 22380070F
D9014 C-DIODE DA2J10100 1 223303R2
D9014 or C-DIODE 1SS352 ( 1) 223234R2
D9015 C-DIODE DA2J10100 1 223303R2
D9015 or C-DIODE 1SS352 ( 1) 223234R2
D9016 ZENER D DZ2J062M0L 1 224760620R2
D9016 or ZENER D UDZS6.2B ( 1) 224550620R2
D911 C-DIODE DA2J10100 1 223303R2
D911 or C-DIODE 1SS352 ( 1) 223234R2
