En-22
Specifications
Amplifier Section
Rated Output Power
(IEC)
2 ch x 20 W at 6 ohms, 1 kHz, 2 ch Driven
THD+N (Total Harmonic
Distortion+N)
0.2% (1 kHz, 1 W)
Damping Factor 31 (6
Ω
)
Input Sensitivity and
Impedance (Unbalance)
1000 mV/47 k
Ω
(AUDIO IN)
Frequency Response 80 Hz - 15 kHz/+3 dB, -3 dB
(AUDIO IN, SOUND MODE: DIRECT)
Signal to Noise Ratio 103 dB (AUDIO IN IHF-A)
Bluetooth Section
Communication System Bluetooth Version 2.1 +EDR
Maximum
communication range
10 m*1
Frequency band 2.4 GHz - 2.48 GHz
Modulation method FHSS (Freq Hopping Spread Spectrum)
Compatible Bluetooth
profiles
A2DP 1.2
AVRCP 1.0
Supported Codec SBC
*1 The actual range will vary depending on factors such as obstacles between devices, magnetic
fields around a microwave oven, static electricity, cordless phone, reception sensitivity, antenna’s
performance, operating system, software application, etc.
