Onkyo TX-8050S - Page 44

U0024
ETC Boar
d
BAETC-0708-1C 1 1B2595708-1C
N
<B MDC>
U0024
ETC Boar
d
BAETC-0708-1D 1 1B2595708-1D
N
<B MPP / S MPP>
CIRCUIT
N
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4001 ZENER D MTZJ6.8B 1 224470682T
D4002 ZENER D MTZJ6.8B 1 224470682T
D4003 ZENER D MTZJ5.6B 1 224470562T
D5001 ZENER D MTZJ5.6B 1 224470562T
D5002 ZENER D MTZJ5.6B 1 224470562T
D5003 C-DIODE DA2J10100 1 223303R2
NSP
D5003 or C-DIODE 1SS352 ( 1) 223234R2
NSP
D5003 or C-DIODE 1SS355 ( 1) 223269R2
NSP
D5003 or C-DIODE MA2J111 ( 1) 223279R2
NSP
D5003 or C-DIODE KDS4148U ( 1) 223283R2
NSP
D5004 C-DIODE DA2J10100 1 223303R2
NSP
D5004 or C-DIODE 1SS352 ( 1) 223234R2
NSP
D5004 or C-DIODE 1SS355 ( 1) 223269R2
NSP
D5004 or C-DIODE MA2J111 ( 1) 223279R2
NSP
D5004 or C-DIODE KDS4148U ( 1) 223283R2
NSP
D5101 ZENER D DZ2J033M0L 1 224760330R2
D5101 or ZENER D UDZS3.3B ( 1) 224550330R2
D5102 ZENER D DZ2J068M0L 1 224760680R2
D5102 or ZENER D UDZS6.8B ( 1) 224550680R2
D5201 C-DIODE DA2J10100 1 223303R2
NSP
D5201 or C-DIODE 1SS352 ( 1) 223234R2
NSP
D5201 or C-DIODE 1SS355 ( 1) 223269R2
NSP
D5201 or C-DIODE MA2J111 ( 1) 223279R2
NSP
D5201 or C-DIODE KDS4148U ( 1) 223283R2
NSP
D5202 C-DIODE DA2J10100 1 223303R2
NSP
D5202 or C-DIODE 1SS352 ( 1) 223234R2
NSP
D5202 or C-DIODE 1SS355 ( 1) 223269R2
NSP
D5202 or C-DIODE MA2J111 ( 1) 223279R2
NSP
D5202 or C-DIODE KDS4148U ( 1) 223283R2
NSP
D5203 ZENER D DZ2J033M0L 1 224760330R2
D5203 or ZENER D UDZS3.3B ( 1) 224550330R2
D5301 DIODE 1SS133 1 223163T
D5302 DIODE 1SS133 1 223163T
D5501 C-DIODE DA2J10100 1 223303R2
NSP
D5501 or C-DIODE 1SS352 ( 1) 223234R2
NSP
D5501 or C-DIODE 1SS355 ( 1) 223269R2
NSP
D5501 or C-DIODE MA2J111 ( 1) 223279R2
NSP
D5501 or C-DIODE KDS4148U ( 1) 223283R2
NSP
D5502 C-DIODE DA2J10100 1 223303R2
NSP
D5502 or C-DIODE 1SS352 ( 1) 223234R2
NSP
D5502 or C-DIODE 1SS355 ( 1) 223269R2
NSP
D5502 or C-DIODE MA2J111 ( 1) 223279R2
NSP
D5502 or C-DIODE KDS4148U ( 1) 223283R2
NSP
D922 C-DIODE S1NB60-4062 1 22380318R2
NSP
