Onkyo TX-8220

Bluetooth
®
Transforms Mobile Audio
Into Room-filling Sound
With low-latency Bluetooth 4.1 wireless technology, you can
stream almost any audio that’s playing on your smartphone,
tablet, laptop, or PC applications. Auto Connect function
makes pairing up and playing back your music much faster and
easier than before, with enhanced stability reducing loss in
audio quality.
Connects Your Turntable, CD Player, TV, and
Media Streamer
Aimed at music and film lovers that want to add great sound
to a variety of media sources, the TX-8220 comes extensively
equipped with audio connections. The receiver is one of the
few at this price to include a quality MM phono stage for your
turntable. It also has digital inputs to route audio from
TV through amp and speakers. Four analog line inputs are
included should you prefer your source device to handle
D/A conversion, or for connecting a phone or DAP.
Rich and Powerful Hi-fi Sound
Pair the TX-8220 with your choice of loudspeakers and add
high-fidelity sound to everyday entertainment, from streaming
audio to TV programs, vinyl, and CD. Discrete amplifiers,
massive EI transformer, and customized capacitors deliver
ample driving power with low distortion. High current grips
the speaker cones for more accurate control, restoring vitality
and detail to music. Non-phase-shift circuitry, meanwhile,
clearly focuses the audio image.
High Current and Low Impedance Architecture
Dynamic passages in music and film soundtracks can see
impedance spike and dip dramatically for short periods. This
can place up to 10 times the usual load on your amplifier, and
if it can’t meet power demands, sound quality suffers. Onkyo’s
high-current low-impedance WRAT design uses a massive
EI transformer to drive your speakers accurately, even under
heavy loads.
FM/AM Tuner with 40 Memory Presets
Scan, name, and save 40 FM and AM radio stations for easy
one-touch recall anytime. Bring a huge variety of programming
to your listening space, from news and sport to music and
talk radio.
A/B Speaker Posts for Multi-room Audio
TX-8220 features two sets of speaker posts enabling
connection of two pairs of speakers. The receiver is designed
to drive either a single pair of speakers rated at 4–16 Ohms,
or two pairs of 8–16 Ohms speakers, allowing you to enjoy
the same audio source in two rooms at once, or to easily
switch between two sets of speakers.
Bass, Treble, and Balance Controls
Bass, treble, and balance buttons are useful for adjusting the
tone characteristics of your music for satisfying response with
any speaker type. Carefully designed tone circuits—which
some receivers don’t include—let you personalize sound to
taste with no perceived loss in audio quality.
TX-8220
Stereo Receiver
SPECIFICATIONS
Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance without notice. The Bluetooth
®
word mark and logos are owned by the Bluetooth SIG, Inc. WRAT is a trademark of Onkyo Corporation.
All other trademarks and registered trademarks are the property of their respective holders.
NPR No. 17N32 08/17
http://www.onkyo.com/
Copyright © 2017 Onkyo Corporation. All rights reserved.
Amplifier Section
Power Output 45 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08%,
2 Channels Driven, FTC)
100 W/Ch (6 Ohms, 1 kHz, 10% THD,
2 Channels Driven)
Dynamic Power 140 W (3 Ohms, Front)
120 W (4 Ohms, Front)
80 W (8 Ohms, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, Half Power)
Input Sensitivity and Impedance
Line 450 mV/40 k-ohms
Phono MM 10 mV/50 k-ohms (IHF-A)
Rated RCA Output Level and Impedance
420 mV/2.2 k-ohms (Line-Out)
2.8 mV/3.3 k-ohms (Subwoofer Pre-Out)
Phono Overload 40 mV (MM, 1 kHz, 0.5%)
Frequency Response 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
Tone Control ±12 dB, 100 Hz (Bass)
±12 dB, 10 kHz (Treble)
Signal-to-Noise Ratio 100 dB (IHF-A, Line In, Speaker Out)
93 dB (IHF-A, Phono In, Speaker Out)
Speaker Impedance 4 Ohms–16 Ohms (A or B)
8 Ohms–16 Ohms (A + B)
Headphone Output Impedance
390 Ohms
Headphone Rated Output 60 mW (32 Ohms, 1 kHz, 10%)
Tuner Section
Tuning Frequency Range
FM 87.5 MHz–107.9 MHz
AM 530 kHz–1,710 kHz
FM/AM Preset Memory 40 Stations
General
Power Supply AC 120 V, 60 Hz
Standby Power Consumption
0.4 W
No-Sound Power Consumption
20 W
Dimensions (W x H x D) 17
1
/
8
˝ x 5
7
/
8
˝ x 12
15
/
16
˝
(435 x 149 x 328 mm)
Weight 15.0 lbs. (6.8 kg)
UPC CODE
(B) 889951001096
CARTON
Dimensions (W x H x D) 21˝ x 9
3
/
16
˝ x 15
13
/
16
˝
(533 x 234 x 401 mm)
Weight 19.0 lbs. (8.6 kg)
Supplied Accessories
• Indoor FM antenna • AM loop antenna • Instruction manual
• Remote controller • AAA (R03) batteries x 2
Text on receiver may vary with region.
