Onkyo TX-DS484

10
• If you want to use the surround effects, connect surround speakers. For the best results, connect a center speaker.
• Use FRONT SPEAKERS B terminals to connect a second pair of front speakers.
• This receiver is designed to produce optimum sound quality when speakers with impedances within the specified ranges are con-
nected. Please check the following information and choose speakers with appropriate impedances for the connections.
FRONT SPEAKERS: A or B: 6 ohms min./speaker
SURROUND SPEAKERS: 6 ohms min./speaker
CENTER SPEAKER: 6 ohms min.
15 mm
2. Unscrew.
1. Twist wire ends very tight.
3. Insert the wire. 4. Screw.
REMOTE CONTROL
CD
AM
FM
75
ANTENNA
GND
PHONO
R
L
R
L
(
PLAY
)
(
REC
)
OUT
I
N
MONI
-
TOR
OUT
SUB
WOOFER
PRE OUT
SURROUND
21
FRONT
R
R
A
B
L
L
R
L
TAPE
VIDEO 1
CENTER
SUB
WOOFER
R
L
V
VIDEO 2
DVD
CENTER
R L
DIGITAL INPUT
FRONT SPEAKERS
RL
SPEAKER
CENTER
SPEAKERS
SURROUND
COAXIAL COAXIAL OPTICAL
MULT I CH I NPUT
OUT
I N
I N
I N
TX-DS484
AC OUTLETS
AC 230V 50Hz
SWITCHED
TOTAL 100W MAX.
+–+–
+–+–
L ch.
R ch.
R ch.
L ch.
+–+–
R ch.
L ch.
Front Speakers A
Front Speakers B
Surround Speakers
Active subwoofer
–+
Center Speaker
NO
Connecting the speaker cable
NOTE:
To prevent damage to circuitry,
never short-circuit the positive (+)
and negative (–) speaker wire.
• When you use only one speaker or wish to listen
to monaural (mono) sound, a single speaker
should never be connected in parallel to both the
right and left channel terminals simultaneously.
+––+ +––+
RL RL
Connecting speakers
