Specifications
TX-DS777
AMPLIFIER SECTION
Continuous Average Power output (FTC)
All channels: 105 watts per channel min. RMS at 8
ohms, 2 channels driven from 20 Hz
to 20 kHz with no more than 0.08%
total harmonic distortion.
135 watts min. RMS at 6 ohms, 2
channels driven from 1 kHz with no
more than 0.1% total harmonic dis-
tortion.
Continuous Power output (DIN) 140 watts at 6 ohms
Maximum Power output (EIAJ) 170 watts at 6 ohms
Total Harmonic Distortion: 0.08% at rated power (Front)
IM Distortion: 0.08% at rated power (Front)
Damping Factor: 60 at 8 ohms (Front)
Input Sensitivity and Impedance
PHONO: 2.5 mV, 50 kohms
LINE (CD, TAPE, DVD,
VIDEO 1, 2, 3,4): 200 mV, 50 kohms
MULTICHANNEL INPUT
(FRONT L/R, SURROUND L/R, CENTER):
200 mV, 50 kohms
(SUBWOOFER): 36 mV, 50 kohms
COAXIAL 1, 2 (DIGITAL): 0.5 Vp-p, 75 ohms
Output Level and Impedance
Rec out (TAPE, VIDEO 1): 200 mV, 2.2 kohms
Pre out: 1 V, 470 ohms
Phono Overload: 110 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency Response:
20 Hz to 100 kHz, +1/-3 dB(LINE INPUT)
RIAA Deviation: 20 Hz to 20 kHz, ±0.8 dB
Tone Control
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Signal-to-Noise Ratio
Phono: 80 dB (IHF A, 5 mV input)
CD/Tape: 100 dB (IHF A)
VIDEO SECTION
Input sensitivity/Impedance
(DVD, VIDEO 1, 2, 3,4)
VIDEO (Composite): 1 Vp-p, 75 ohms
Output Level/Impedance
(VIDEO 1, 2, MONITOR)
VIDEO (Composite): 1 Vp-p, 75 ohms
TX-DS676
AMPLIFIER SECTION
Continuous Average Power output (FTC)
All channels: 85 watts per channel min. RMS at 8
ohms, 2 channels driven from 20 Hz
to 20 kHz with no more than 0.08%
total harmonic distortion.
110 watts min. RMS at 6 ohms, 2
channels driven from 1 kHz with no
more than 0.1% total harmonic dis-
tortion.
Continuous Power output (DIN) 115 watts at 6 ohms
Maximum Power output (EIAJ) 145 watts at 6 ohms
Total Harmonic Distortion: 0.08% at rated power (Front)
IM Distortion: 0.08% at rated power (Front)
Damping Factor: 60 at 8 ohms (Front)
Input Sensitivity and Impedance
PHONO: 2.5 mV, 50 kohms
LINE (CD, TAPE, DVD,
VIDEO 1, 2, 3,4): 200 mV, 50 kohms
MULTICHANNEL INPUT
(FRONT L/R, SURROUND L/R, CENTER):
200 mV, 50 kohms
(SUBWOOFER): 36 mV, 50 kohms
COAXIAL 1, 2 (DIGITAL): 0.5 Vp-p, 75 ohms
Output Level and Impedance
Rec out (TAPE, VIDEO 1): 200 mV, 2.2 kohms
Pre out: 1 V, 470 ohms
Phono Overload: 110 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency Response:
20 Hz to 100 kHz, +1/-3 dB(LINE INPUT)
RIAA Deviation: 20 Hz to 20 kHz, ±0.8 dB
Tone Control
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Signal-to-Noise Ratio
Phono: 80 dB (IHF A, 5 mV input)
CD/Tape: 100 dB (IHF A)
VIDEO SECTION
Input sensitivity/Impedance
(DVD, VIDEO 1, 2, 3,4)
VIDEO (Composite): 1 Vp-p, 75 ohms
Output Level/Impedance
(VIDEO 1, 2, MONITOR)
VIDEO (Composite): 1 Vp-p, 75 ohms
