Onkyo TX-DS787

73
Specifications
AMPLIFIER SECTION
Continuous Average Power output (FTC)
All channels: 100 W per channel min. RMS at
8 Ω, 2 channels driven from 20
Hz to 20 kHz with no more than
0.08% total harmonic distortion.
130 W min. RMS at 6 Ω, 2
channels driven from 1 kHz with
no more than 0.1% total
harmonic distortion.
Continuous Power output (DIN) 135 W at 6 Ω
Maximum Power output (EIAJ) 160 W at 6 Ω
Dynamic Power Output (Stereo) 2 × 250 W at 3 Ω
2 × 210 W at 4 Ω
2 × 130 W at 8 Ω
Total Harmonic Distortion: 0.08% at rated power
0.08% at 1 W output
IM Distortion: 0.08% at rated power
0.08% at 1 W output
Damping Factor: 60 at 8 Ω
Input Sensitivity and Impedance
PHONO: 2.5 mV, 50 kΩ
LINE (CD, TAPE, DVD,
VIDEO 1-4): 200 mV, 50 kΩ
MULTICHANNEL INPUT
(FRONT L/C/R, SURROUND
L/R, SURROUND BACK L/R):200 mV, 50 kΩ
(SUBWOOFER): 36 mV, 50 kΩ
COAXIAL 1, 2 (DIGITAL): 0.5 Vp-p, 75 Ω
DVD, VIDEO1-4: 1 Vp-p, 75 Ω
1 Vp-p, 75 Ω (Y)
0.28 Vp-p, 75 Ω (C)
COMPONENT VIDEO 1, 2: 1 Vp-p, 75 Ω (Y)
0.7 Vp-p, 75 Ω (P
B, PR)
Output Level and Impedance
Rec out (TAPE, VIDEO 1, 2):
200 mV, 2.2 kΩ
Pre out: 1 V, 470 Ω
VIDEO (VIDEO 1, 2, MONITOR OUT):
1 Vp-p, 75 Ω
1 Vp-p, 75 Ω (Y)
0.28 Vp-p, 75 Ω (C)
COMPONENT VIDEO OUT: 1 Vp-p, 75 Ω (Y)
0.7 Vp-p, 75 Ω (P
B, PR)
Phono Overload:
110 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency Response: 20 Hz to 30 kHz: ±1 dB
(CD in Direct mode)
10 Hz to 100 kHz: +1 dB,-3 dB
(CD in Direct mode)
RIAA Deviation: 20 Hz to 20 kHz : ±0.8 dB
Tone Control
Bass: ±12 dB at 100 Hz
Treble: ±12 dB at 10 kHz
Signal-to-Noise Ratio (Stereo)
Phono: 80 dB (IHF A, 5 mV input)
CD/Tape: 100 dB (IHF A, 0.5 V input)
Muting: –50 dB
TUNER SECTION
FM
Tuning Range: 87.5 to 108.0 MHz (50-kHz steps)
Usable Sensitivity
Mono: 11.2 dBf, 1.0 µV (75 Ω IHF)
0.9 µV (75 Ω DIN)
Stereo: 17.2 dBf, 2.0 µV (75 Ω IHF)
23 µV (75 Ω DIN)
50 dB Quieting Sensitivity
Mono: 17.2 dBf, 2.0 µV (75 Ω)
Stereo: 37.2 dBf, 20 µV (75 Ω)
Capture Ratio: 2.0 dB
Image Rejection Ratio:
USA & Canadian models: 40 dB
Other area models: 85 dB
IF Rejection Ratio: 90 dB
Signal-to-Noise Ratio
Mono: 76 dB
Stereo: 70 dB
Alternate Channel Attenuation: 55 dB
Selectivity: 50 dB (DIN)
AM Suppression Ratio: 50 dB
Total Harmonic Distortion
Mono: 0.2%
Stereo: 0.3%
Frequency Response: 30 Hz to 15 kHz, ±1.0 dB
Stereo Separation: 45 dB at 1 kHz
30 dB at 100 Hz to 10 kHz
AM
Tuning Range
USA & Canadian models: 530 to 1,710 kHz (10-kHz steps)
European & Australian models : 522 to 1,611 kHz (9-kHz steps)
Worldwide models: 531 to 1,602 kHz (9-kHz steps)
530 to 1,710 kHz (10-kHz steps)
Usable Sensitivity: 30 µV
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 40 dB
Signal-to-Noise Ratio: 40 dB
Total Harmonic Distortion: 0.7%
GENERAL
Power Supply: AC 120 V, 60 Hz
(USA & Canadian models)
AC 230-240 V, 50 Hz
(European & Australian models)
AC 220-230 V, 50/60 Hz
(some Asian models)
AC 220-230 and 120 V switchable,
50/60 Hz (Worldwide models)
Power Consumption: 5.5 A
440 W
Dimensions (W × H × D): 435 × 175 × 453 mm
17-1/8" × 6-7/8" × 17-13/16"
Weight: 36.6 lbs. (USA & Canadian models)
16.9 kg (European models)
17.6 kg
(Australian & worldwide models)
17.4 kg (some Asian models)
REMOTE CONTROLLER
Transmitter: Infrared
Signal range: Approx. 5 meters, 16 ft.
Power supply: Two “AA” batteries (1.5 V × 2)
Specifications and features are subject to change without notice.
Power supply and voltage vary depending on the area in which the unit
is purchased.
