Onkyo TX-L50 User Manual

24
> Before Start > Part Names > Install > Initial Setup >Playback
Supplementary Information | Advanced Setup | Others
E
N
Music Server
It is possible to stream music files stored on PCs or NAS
devices connected to the same network as this unit. The
network servers this unit is compatible with are those PCs
with players installed that have the server functionality of
Windows Media
®
Player 11 or 12, or NAS that are
compatible with home network functionality. You may need
to make some settings in advance to use Windows Media
®
Player 11 or 12. Note that only music files registered in the
library of Windows Media
®
Player can be played.
Configuring Windows Media
®
Player
■ Windows Media
®
Player 11
1. Turn on your PC and start Windows Media
®
Player 11.
2. In the "Library" menu, select "Media Sharing" to display a
dialog box.
3. Select the "Share my media" check box, and then click
"OK" to display the compatible devices.
4. Select this unit, click "Allow" and put a check mark next to
the icon for this unit.
5. Click "OK" to close the dialog.
0 Depending of the version of Windows Media
®
Player,
there may be differences in the names of items you can
select.
■ Windows Media
®
Player 12
1. Turn on your PC and start Windows Media
®
Player 12.
2. In the "Stream" menu, select "Turn on media streaming"
to display a dialog box.
0 If media streaming is already turned on, select "More
streaming options..." in the "Stream" menu to list players
in the network, and then go to step 4.
3. Click "Turn on media streaming" to list players in the
network.
4. Select this unit in "Media streaming options" and check
that it is set to "Allow".
5. Click "OK" to close the dialog.
0 Depending of the version of Windows Media
®
Player,
there may be differences in the names of items you can
select.
Playing
1. Start the server (Windows Media
®
Player 11, Windows
Media
®
Player 12, or NAS device) containing the music
files to play.
2. Make sure that the PCs and/or NASs are properly
connected to the same network as this unit.
3. Switch the input on the TV to that assigned to the unit.
4. Press NET on the remote controller.
5. With the cursors on the remote controller, select "Music
Server", and then press ENTER (b).
6. Select the target server with the cursors on the remote
controller and press ENTER (b) to display the items list
screen.
7. With the cursors on the remote controller, select the
music file to play, and then press ENTER (b) to start
playback. To return to the previous screen, press (d).
0 If "No Item." is displayed, check whether the network is
properly connected.
0 Depending on the server and share settings, the unit may
not recognize it, or may not be able to play its music files.
Furthermore, the unit cannot access pictures and videos
stored on servers.
0 For music files on a server, there can be up to 20,000
tracks per folder, and folders may be nested up to 16
levels deep.
a
c
d
b
e
f
g
h
1

Onkyo TX-L50 Specifications

General

Receiver type	Surround
Frequency range	10 - 40000 Hz
Audio output channels	5.1 channels
Total Harmonic Distortion (THD)	1 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	4
USB ports quantity	0
Digital audio optical in	1
Headphone connectivity	3.5 mm
Speakers connectivity type	-
Wi-Fi	Yes
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	40
Product color	Black
Apple docking compatibility	Not supported
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.38 W
Power consumption (typical)	60 W
Package weight	5500 g

Weight and Dimensions

Depth	325.5 mm
Width	435 mm
Height	70 mm
Weight	4000 g
