■ 4. Level Calibration ∫ 5. Dolby Enabled Speaker
0 This setting can only be selected when you have set "Configuration" - "Height Speaker" to
"Dolby Speaker".
■ 6. Equalizer Settings
You can adjust the output volume of the range of each connected speaker. You can adjust
the volume of the different sound ranges for each of the speakers. You can set three
different equalizers in Preset 1 to 3. You can select up to 5 bands for the Subwoofer and 9
bands for all other speakers. To use the set equalizer effects, select the preset number in
"QUICK MENU"- "AccuEQ" - "Equalizer" (ÄP50).
Front Left Select a value between "j12 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Center Select a value between "j12 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Front Right Select a value between "j12 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Height Left Select a value between "j12 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level. (Default Value is "0 dB")
Height Right Select a value between "j12 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level. (Default Value is "0 dB")
Surround Right Select a value between "j12 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Surround Left Select a value between "j12 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Subwoofer Select a value between "j15 dB" and "i12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Dolby Enabled
Speaker to Ceiling
Set the distance between the Dolby enabled speaker and the
ceiling. Select a value between "0.1 ft/0.03 m" and "15.0 ft/
4.50 m" (in 0.1 ft/0.03 m increments, default value is "1.80 m")
0 The unit of distance (feet/meters) shown is the unit selected
for use in "Distance".
AccuReflex You can enhance the reflection effect of Dolby enabled speaker
from the ceiling.
"On": When this function is to be used
"Off (default value)": When this function is not to be used
0 The function is not effective if the listening mode is Direct.
Front After selecting the speaker frequency from between "25 Hz" and
"16 kHz" with the cursors W/X, adjust the volume of that
frequency between "j6.0 dB" and "i6.0 dB" with S/T. (Default
Value is "0.0 dB")
Center After selecting the speaker frequency from between "25 Hz" and
"16 kHz" with the cursors W/X, adjust the volume of that
frequency between "j6.0 dB" and "i6.0 dB" with S/T. (Default
Value is "0.0 dB")
Height After selecting the speaker frequency from between "25 Hz" and
"16 kHz" with the cursors W/X, adjust the volume of that
frequency between "j6.0 dB" and "i6.0 dB" with S/T. (Default
Value is "0.0 dB")
