Onkyo TX-SR707

1/136 PAGE
PARTS LIST TX-SR707
<NOTES>
! : Safety mark
NSP : Not service parts
<B> : Black color
<S> : Silver color
<G> : Golden color
<MDC> : Canadian model
<MMO> : Saudi Arabia model
<MMP> : European model
<MDF> : Taiwan model
<MMA> : Australian model
<MMR> : China model
<MMQ> : Hongkong model
<MMB> : Britain model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DRESCRIPTION Q'TY PART NO. REMARKS
EXP V
F1
A001 CHASSIS --
1
27100537A
NSP
EXP V
F1
A003 BOTTOM LEG TX-SR506
4
27175441A LEG(ELAST)
EXP V
F1
A011 SCREW 3TTB+10B(3BC)
4
838430108GR LEG
EXP V
F1
A013 WASHER W3*8F(3CM)
4
87613008GR LEG(ELAST)
EXP V
F1
A015 SCREW 4TTC+8C(3BC)
4
830440089GR TRANS
EXP V
F1
A017 SPACER --
1
27270439 TRANS
EXP V
F1
A019 CUSHION T10*30*10EPT
1
28141822 TRANS-BTM
EXP V
F1
A027 HEAT SINK --
1
27160609A
EXP V
F3
A031 SCREW 3SMS8W.SW+14B(CU)
14
801634 POWER-TR
EXP V
F1
A033 SCREW 3TTB+8B(3CM)SR
1
801637 THERMISTER
EXP V
F1
A037 RETAINER (HT-R7)
1
27142114
EXP V
F1
A039 RETAINER (HT-L7)
1
27142113
EXP V
F1
A044 SCREW 3TTB+8B(3CM)SR
2
801637 AMP0072-CLA0087
EXP V
F1
A045 SCREW 3TTB+8B(3CM)SR
4
801637 HSINK-RET(HT)
N
OTE : THE COMPONENTS IDENTIFIED BY THE MAR
K
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
