Onkyo TX-SR707

9/136 PAGE
EXP V
F1
U012 Video circuit PC board a'ssy BAVD-0101-1B
1
1B234501-1B
N <MMA>
EXP V
F1
U012 Video circuit PC board a'ssy BAVD-0101-1B
1
1B234501-1B
N <MMR>
EXP V
F1
U013 Universal port terminal PC board a'ssy BAETC-0103-1A
1
1B234503-1A
N <MDC>
EXP V
F1
U013 Universal port terminal PC board a'ssy BAETC-0103-1B
1
1B234503-1B
N <MMO>
EXP V
F1
U013 Universal port terminal PC board a'ssy BAETC-0103-1B
1
1B234503-1B
N <MMP>
EXP V
F1
U013 Universal port terminal PC board a'ssy BAETC-0103-1B
1
1B234503-1B
N <MMQ>
EXP V
F1
U013 Universal port terminal PC board a'ssy BAETC-0103-1A
1
1B234503-1A
N <MDF>
EXP V
F1
U013 Universal port terminal PC board a'ssy BAETC-0103-1B
1
1B234503-1B
N <MMA>
EXP V
F1
U013 Universal port terminal PC board a'ssy BAETC-0103-1B
1
1B234503-1B
N <MMR>
EXP V
F2
U014 Display circuit PC board a'ssy BADIS-0110-1A
1
1B234510-1A
N All Destinations
EXP V
F2
U015 Standby switch PC board a'ssy BASW-0111-1A
1
1B234511-1A
N All Destinations
EXP V
F2
U016 FL power supply PC board a'ssy BAPS-0112-1A
1
1B234512-1A
N All Destinations
EXP V
F1
U017 Headphone terminal PC board a'ssy BAETC-0113-1A
1
1B234513-1A
N All Destinations
EXP V
F1
U018 FFC Support PC board BAETC-0114-1A
1
1B234514-1A
N All Destinations
EXP V
F2
U019 AUX input terminal PC board a'ssy BAETC-0115-1A
1
1B234515-1A
N All Destinations
EXP V
F2
U020 Volume illuminate PC board a'ssy BAETC-0116-1A
1
1B234516-1A
N All Destinations
EXP V
F1
U021 Support-1 PC board BAETC-0117-1A
1
1B234517-1A
N All Destinations
EXP V
F2
U022 Support-2 PC board BAETC-0118-1A
1
1B234518-1A
N All Destinations
EXP V
F1
U023 HDMI circuit PC board a'ssy BAHDM-0132-1A
1
1B234532-1A
N All Destinations
EXP V
F2
U024 Front HDMI terminal PC board a'ssy BAHDM-0290-1A
1
1B234590-1A
N All Destinations
EXP V
F1
U030 TUNER UNIT FAEH06-A01US
1
240166
<MDC><MDF>
EXP V
F1
U030 TUNER UNIT FAEH06-E01EX
1
240165
Except <MDC>
PACKING VIEW PARTS LIST
TX-SR707
REF. NO. PART NAME DRESCRIPTION Q'TY PART NO. REMARKS
PKG
A653 PAD ASTXSR707
1
29092462A 707/40.1
PKG
A655 SHEET (PAD)
1
29096065A 707/40.1
PKG
A657 SHEET 1300*650
1
29095966
PKG
A663 TAPE (SEROHAN)NITTO NO.29
1
29110149 :0.3:MT::
PKG
A665 PP TAPE W50 SBT-70
1
29110200 :1.6:MT::
PKG
A701 CARTON TXSR707DC
1
29055003
N <MDC><MDF>
PKG
A701 CARTON TXSR707MP
1
29055004
N Except <MDC><MDF>
