Onkyo TX-SR707 - Page 39

11/136 PAGE
PKG
A872 INS MANUAL Cs(QSS)(TX-SR707)
1
29400019
N <MMR>
PKG
A874 INS MANUAL (QC ImportantSheet)
1
29344267A
<MMO>
PKG
A875 INS MANUAL U9(RC736/737/738/739)
1
29344962
PKG
A881 INST SHEET WEEE
1
29355537A
<MMP>
PKG
A882 HANDBILL (SIRIUS)
1
29380149
<MDC>
PKG
A883 INST SHEET En(2009E_RIHD)
1
29355745
PKG
A884 INST SHEET U2FrEs(2009E_RIHD)
1
29355746
<MDC>
PKG
A885 INST SHEET U8(2009E_RIHD)
1
29355747
Except <MDC>
PKG
A887 INST SHEET Ct(CHUISI_MDF)
1
29355749
<MDF>
PKG
A890 HANDBILL (UP-A1)US
1
29380155
<MDC>
PKG
A890 HANDBILL (UP-A1)EU
1
29380156
<MMP>
PKG
P903 CV PLUG SCP-13A-BLK(UK)
1
25056591
! <MMO>
PKG
P901 AC CORD AS-CEE-3
1
253298VOL
! <MMO>
PKG
P901 AC CORD AS-CEE-3
1
253298VOL
! <MMP>
PKG
P901 AC CORD AS-BS
1
253425YUN
! <MMQ>
PKG
P901 AC CORD AS-SAA
1
253391VOL
! <MMA>
PKG
P901 AC CORD AS-CCC
1
253358VOL
! <MMR>
PRINTED CIRCUIT BOARD PARTS LIST TX-SR707
U001 Amplifire circuit PC board BAAMP-0072-1A/1B
U002 Audio in/out circuit PC board BAASP-0073-1A/1B
U003 Thermister PC board BAETC-0074-1A/1B
U004 AC Inlet terminal PC board BAETC-0089-1B
PCB
NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
AMP0072
C4604 C-CERA C CC725CH1H-101J1 1 342101014R1
AMP0072
C4605 C-CERA C CK725F1E-104Z1 1 332161040R1
AMP0072
C5503 UPZ C 2AUPZTF221JE 1 376332214T
AMP0072
C5504 UPZ C 2AUPZTF221JE 1 376332214T
AMP0072
C5505 C-CERA C CC725CH1H-221J1 1 342102214R1
AMP0072
C5506 C-CERA C CC725CH1H-221J1 1 342102214R1
