Onkyo TX SR804

27
Connecting Your Components—Continued
•With connection , you can listen to and record audio from a DVD and listen in Zone 2.
•To enjoy Dolby Digital and DTS, use connection or . (For recording, use and , or and .)
• If your DVD player has main left and right outputs and multichannel left and right outputs, be sure to use the
main left and right outputs for connection .
Connecting a DVD player
Connection AV receiver Signal flow DVD player Picture quality
COMPONENT VIDEO IN 1
⇐
Component video output Best
DVD IN S
⇐
S-Video output Better
DVD IN V
⇐
Composite video output Standard
DVD IN FRONT
⇐
Analog audio L/R output
DIGITAL COAXIAL IN 1
⇐
Digital coaxial output
DIGITAL OPTICAL IN 4
⇐
Digital optical output
Step 1: Video Connection
Choose a video connection that matches your DVD player ( , , or
), and then make the connection.
If you use connection , you must connect the AV receiver to your TV with the same type of connection.
A B C
A
Step 2: Audio Connection
Choose an audio connection that matches your DVD player ( , , or ), and then make the connection.
a
b c
a
b c a b a c
a
A
B
C
a
b
c
COAXIAL
IN 1
YCOAXIAL
OUT
PB
COMPONENT VIDEO OUT
P
R S VIDEO
OUT
AUDIO
OUT
VIDEO
OUT
DVD
IN
V
S
DVD
IN
LR
OPTICAL
OUT
OPTICAL
IN 4
COMPONENT VIDEO
IN 1
L
R
FRONT
IN
Y
C
B/PB
CR/PR
b
c
A
B
C
B
a
C
DVD player
To connect a DVD player or DVD-Audio/SACD-capable player with a
multichannel analog audio output, see page 28.
Connect one
or the other
