CPU / System & Graphics Stress
25.0
25.6
S3
3.55
3.70
S5
0.75
0.81
Deep S5
0.05
0.17
Config 3 High HX330
Power Consumption
8V (avg W)
24V (avg W)
Windows Idle
11.0
11.7
CPU / system Stress
21.4
21.3
CPU / System & Graphics Stress
23.7
25.2
S3
3.79
3.85
S5
0.81
0.86
Deep S5
0.05
0.17
6.2 - Appendix B: Isolated DIO guide
Additional information for the Isolated DIO can be found on the OnLogic support site. Please refer to
the link below for additional information.
https://www.onlogic.com/support/documentation/hx300-technical-resources
6.3 - Appendix C: BIOS manual
For a detailed overview of the BIOS screens and individual settings, please refer to the OnLogic
support site. Instructions for updating the BIOS can also be found on the support site. Please refer to
the link below for detailed instructions.
https://www.onlogic.com/support/documentation/hx300-technical-resources
6.4 - Appendix D: CAN user guide
Additional information for using the on-board CAN transceiver can be found on the OnLogic support
site. Please refer to the link below for additional information.
https://www.onlogic.com/support/documentation/hx300-technical-resources
