Onlogic HX310 - Product Specifications; General Specifications (Dimensions, CPU, Memory); Connectivity and Expansion

1.3 - Product Specifications
Model
HX310
HX330
System Dimensions
196x37x120 mm (TBD)
same
Motherboard
Dimensions
114 x 175 mm max (TBD)
same
CPU
Celeon N6211 6W, 2 Cores or Pentium
J6426 - 10 W, 4 Cores
Celeon N6211 6W, 2 Cores or Pentium
J6426 - 10 W, 4 Cores
Memory
2 x SO-DIMM (2 x 16 max Dual Channel) 32
GB Total
2 x SO-DIMM (2 x 16 max Dual Channel) 32
GB Total
LAN controller
1x Intel GPY115 or 2x Intel GPY115 with
Pentium J6426
1x Intel GPY115 or 2x Intel GPY115
Expansion
1x M.2 2280/60/3042 B-Key (PCIe x 1, USB
3.0, SATA III)
1x M.2 2230 E-key (Wi-Fi) (PCIe / USB 2.0)
1x M.2 2280 M-key (PCIe x 2, SATA III)
1x M.2 2230 E-key (Wi-Fi) (PCIe / USB 2.0)
1x M.2 2280 M-key (PCIe x 2, SATA III)
Optional Add On
Module
4G/5G, CAN Bus, Coral VPU
Dual LAN
Back I/O
3x Full size DisplayPort 1.4 with CEC
support by optional add-on module
1 x Gb LAN (2 Gb LAN optional with
Pentium J6426)
2x USB 3.1 (Host Gen 2)
2x USB 2.0
Terminal Block Option - Punch out
3x Antenna punch outs
Barrel Jack with 12~24 V input
1x Kang Yang SWPL-3 (Power Cable
Retention)
Kensington Lock
3x Full size DisplayPort 1.4 with CEC
support by optional add-on module
1 x Gb LAN (2 Gb LAN optional with Pentium
J6426)
2x USB 3.1 (Host Gen 2,)
2x USB 2.0
Terminal Block Option - Punch Out
3x Antenna punch outs
Barrel Jack with 12~24 V input
1x Kang Yang SWPL-3 (Power Cable
Retention)
Kensington Lock
Front I/O
1x Power LED button (recessed power
button)
1x USB 2.0
1x USB 3.1 (Host Gen 2)
2FF-Sim slot (Mapped to the B-Key)
1x Serial port (RS-232/422/485)
1x Power LED button (recessed power
button)
2x Gb LAN
1x USB 2.0
1x USB 3.1 (Host Gen 2)
2FF-Sim slot (Mapped to the B-Key)
1x Serial port (RS-232/422/485)
ModBay (Front
plate)
2 DB9 COM ports/CANBus
3 antenna punch outs
10-pin terminal block (for 8-pin DIO)
Dual LAN RJ45
Onboard Headers &
Connectors
1x Battery on a cable
2x Serial Header, RS 232/422/485
1x USB 2.0 (1x5 header)
1x 2-Pin power for devices 5V (J32)
4 Pin in for Terminal Block Power
1x Battery on a cable
2x Serial Header, RS 232/422/485
1x USB 2.0 (1x5 header)
1x 2-Pin power for devices 5V (J32)
4 Pin in for Terminal Block Power
