Onlogic HX310 - Page 6

Auto Power On (AT/ATX Mode Select)
2x6 connector for GPIO x 8 with Interrupt
(including 1 pin power, 2 pin ground, 1
keyed)
CAN-FD Bus 2x5-pin header with key (to use
standard DB9 cable)
2x6 pin CEC header
Auto Power On (AT/ATX Mode Select)
2x6 connector for GPIO x 8 with Interrupt
(including 1 pin power, 2 pin ground, 1
keyed)
CAN-FD Bus 2x5-pin header with key (to use
standard DB9 cable)
2x6 pin CEC header
Voltage Input
rated input: 8~24V via DC jack or onboard
4-pin power header; +/- 10% tolerance
rated input: 8~24V via DC jack or onboard
4-pin power header; +/- 10% tolerance
Power Input
Barrel Jack with optional 4-pin Terminal
Block (support remote switch, Barrel Jack
covered when not in use.)
Barrel Jack with optional 4-pin Terminal
Block (support remote switch, Barrel Jack
covered when not in use.)
Power Protections
TVS for power input protection
Moderate disturbance protection with a TVS
LC filter. Alternate DC supplies should be IT
equipment rated when possible.
TVS for power input protection
Moderate disturbance protection with a TVS
LC filter. Alternate DC supplies should be IT
equipment rated when possible.
BIOS
Insyde
Insyde
Operating Systems
Windows 10 IoT Enterprise, Ubuntu 20.04
LTS (TBD), Yocto
Windows 10 IoT Enterprise, Ubuntu 20.04
LTS (TBD), Yocto
Special Features
Watchdog timer
RTC
PTT in BIOS,
TPM header, Nuvoton NPCT750AABYX
Hardware Autopower on
Watchdog timer
RTC
PTT in BIOS,
TPM header, Nuvoton NPCT750AABYX
Hardware Autopower on
Mounting Options
DIN (edge mount)
Wall
VESA
Desk
DIN (edge mount)
Wall
VESA
Desk
Thermal Standards,
Subject to Change
through RFI and RFQ
steps
System Operating Temperature: 0-50C
Board Operating Temperature: 0-65C
Storage Temperature: -10-85C
Operating Humidity: 0% - 90%
System Operating Temperature: 0-50C
Board Operating Temperature: 0-65C
Storage Temperature: -10-85C
Operating Humidity: 0% - 90%
6
