Onlogic HX310 - Appendix F: Expansion Port Pinout; M.2 B-Key Pinout

6.5 - Appendix F: Expansion port pinout
6.5.1 - M.2 B-Key
Pin
Function
Function
Pin
1
CONFIG_3
3.3V
2
3
GND
3.3V
4
5
GND
FULL_CARD_POWER_OFF#
6
7
USB 2.0 D+
W_DISABLE1#
8
9
USB 2.0 D-
NC
10
11
GND
KEY
12
13
KEY
KEY
14
15
KEY
KEY
16
17
KEY
KEY
18
19
KEY
NC
20
21
CONFIG_0
NC
22
23
NC
NC
24
25
NC
GPIO_10/W_DISABLE2#
26
27
GND
NC
28
29
PERn1/USB3.1-Rx-
UIM-RESET
30
31
PERp1/USB3.1-Rx+
UIM_CLK
32
33
GND
UIM_DATA
34
35
PETn1/USB3.1-Tx-
UIM_PWR
36
37
PETp1/USB3.1-Tx+
NC
38
39
GND
NC
40
41
PERn0/SATA-B+
NC
42
43
PERp0/SATA-B-
NC
44
45
GND
NC
46
47
PETn0/SATA-A-
NC
48
49
PETp0/SATA-A+
PERST#
50
51
GND
CLKREQ#
52
53
REFCLKn
PEWAKE#
54
55
REFCLKp
NC
56
57
GND
NC
58
59
NC
NC
60
61
NC
NC
62
