Power Connection
The rack mountable units (OM2200) may be equipped with built-in single- or dual-
AC or DC power supplies. The small form-factor units (OM1200) use a single
external 12V power adapter.
OM2200 have dual universal AC power supplies with auto failover built in. These
power supplies each accept AC input voltage between 100 and 240 VAC with a fre-
quency of 50 or 60 Hz. The OM2224-24E-10G-L draws a maximum of 48W, while
non-24E are less than 30W.
Two IEC AC power sockets are located on the power side of the metal case, and
these IEC power inlets use conventional IEC AC power cords.
Note: Country specific IEC power cords are not included with OM2200s.
OM1200s are shipped with a 12VDC to universal AC (multicounty clips) wall
adapter.
INSTALLATION AND CONNECTION 10
