READER LEDS
The Openpath Smart Reader’s LEDs indicate the following:
center dot is solid white
outer ring is solid white
center dot quickly switches
between multiple colors and
outer ring quickly spins once
reader has just received power
reader is not connected to power
(check to see if power wires are
swapped)
center dot is flashing red
reader is connected to power but
cannot communicate with the ACU
(check to see if the +B [blue] and -A
[violet] lines are swapped)
reader is connected to power and
can communicate with the ACU, but
has not been configured as an entry
in the Control Center
center dot is solid green and the
outer ring is solid
reader has been identified via the
Control Center
center dot is solid purple and the
outer ring is solid white
reader is possibly not receiving
enough voltage or current,
potentially due to a break in wiring –
try connecting the reader directly to
the ACU, bypassing any wire runs
center dot is solid pink and the
outer ring is solid white
check that +12V IN (orange) hasn’t
been swapped with +B (blue) or -A
(violet)
