TECHNICAL SPECIFICATIONS AND DIMENSIONS - PRIMA series
23
14
25
8
8
23
320
101.5
176.5
20.5
15
33
20
3
25/30/
35/60
38/43/
48/73
UPRIGHT SECURITY SOLENOID LOCK
› Stainless steel face plate and striking plate, hardened steel deadbolt/spring latch
› Versions with fail-safe or fail-secure deadbolt/spring latch
› Power supply: 12 ÷ 24 Vdc, peak current 3 A, holding current 130 ÷ 230 mA
› Ready for interlocking between 2 or more doors
› Opto-electronic control of deadbolt / spring latch position
› Electronic control (can be disabled) of reclosing timings
› Anti-rebound alignment ball (optional)
14
25
8
23
360
96.5
23
8
25
4.5
4.5
4.5
150
12
12
55
OP57036/38 Striking plate
5
3
23
83
