Opera PRIMA - Explanation for Symbols and Indications

7
TECHNICAL SPECIFICATIONS AND DIMENSIONS - CLASSICA series
77
28
3
210
157
90
70
20
160
76.5
10
10
25
240
115.7
23
23
8
25
OP54036/38
266/268
276/278
25
13
160
13
90
30
25
4.5
4.5
150
12
12
55
Striking plate
HORIZONTAL SECURITY SOLENOID LOCK
› Stainless steel face plate and striking plate, hardened steel deadbolt/spring latch
› Versions with fail-safe or fail-secure deadbolt/spring latch
› Power supply: 12 ÷ 24 Vdc, peak current 3 A, holding current 130 ÷ 230 mA
› Ready for interlocking between 2 or more doors
› Opto-electronic control of deadbolt / spring latch position
› Electronic control (can be disabled) of reclosing timings
› Anti-rebound alignment ball (optional)
