TABLE OF FUNCTIONS
Wire colour Function Description
Black Power supply
(non-polarized)
Voltage : 12 ÷ 24 Vdc
Peak current : 3 A
Current (holding) : 300 mA
Black
Orange (green band) Common contact Voltage-free microswitch for remote
signalling of deadbolt position.
See NOTES.
Red (green band) Contact (N.O.)
Brown (green band) Contact (N.C.)
Green / black Signal ground
(GND)
GND reference of each control.
Not the - of power supply.
Red / black Opening Impulsive command for deadbolt
release, from clean N.O. contact.
Brown Door status Door position signalling / alternate
magnetic sensor status. See NOTES
Yellow / black Interlock Input / output of interlock
connection.
See INTERLOCKING DIAGRAM.
Blue Alarm / Failure
(item 246 - 248
only)
Open Collector output for alarm
signalling. See NOTES.
Green RESET
(item 246 - 248
only)
N.O. impulsive contact to be
connected to GND for alarm reset.
Orange Emergency
(item 246 - 248
only)
N.O. impulsive contact to be
connected to GND for the immediate
unlocking of the door.
Yellow Lockout
(item 246 - 248
only)
N.O. contact to be steadily
connected to GND in order to disable
the opening/closing of the deadlock
(excluding Emergency).
