The jam shown in Figure 4-40 can happen when a round or cylindrical item is
placed on the conveyor oriented as shown. The item wants to roll in the
opposite direction on the conveyor causing it to lag. When the item triggers the
first conveyor sensor, a timer is started. If the item doesn’t reach the iBOT
before the timer expires, the track is stopped and the load failure jam message
appears.
Figure 4-40: Load Failure Jam
Item triggers sensor, a
timer starts, but the item
rolls in opposite direction
Item doesn’t reach iBOT
before timer expires,
and the track stops.
Load Failure Jam
message appears
Item kept rolling right through into the reject bin
