34 Safety
Sure Sort™ Operator Manual
OPEX Corporation
2.3.2.3. Height adjustment label
Location: Return conveyor rear, above hand crank, two places (Table 2-14).
Purpose: Provides directions for raising/lowering return conveyor.
Table 2-14: Return Conveyor Height Adjustment label
Label locations Description
Right Side adjustment, All (8166600)
Left Side adjustment, All (8166700)
Back of return conveyor
Left Side label
Right Side label
p/n 8166600 Rev A
p/n 8166700 Rev A
