*) Optical path length (OPL) using standard windows model A is given in column
OPL A-A.
For the TF16 sensor, the sensor body and window combination have to be
chosen so that a type A window is installed on the detector side and the optical
path length is 40 mm (1.58 ''). That means, if a sensor body with 50 mm (1.97 '')
OPL A-A is chosen, a type A window has to be installed on the detector side and
a type C window has to be installed on the lamp side.
Flange
(ASME B16.5 RF, 150 lbs)
0120-0406-03
1.4571 /
SS 316 Ti
welded 2" 40 150 160 195
Flange
(ASME B16.5 RF, 150 lbs)
0120-0606-03
1.4571 /
SS 316 Ti
welded 3" 50 225 165 200
Flange
(ASME B16.5 RF, 150 lbs)
0120-0706-03
1.4571 /
SS 316 Ti
welded 4" 60 230 170 205
Flange
(DIN 2633, E)
0120-1115-03
1.4571 /
SS 316 Ti
welded DN 25 40 150 160 195
Flange
(DIN 2633, E)
0120-1315-03
1.4571 /
SS 316 Ti
welded DN 40 40 150 160 195
Flange
(DIN 2633, E)
0120-0415-03
1.4571 /
SS 316 Ti
welded DN 50 40 150 160 195
Flange
(DIN 2633, E)
0120-0515-03
1.4571 /
SS 316 Ti
welded DN 65 50 150 165 200
Flange
(DIN 2633, E)
0120-0615-03
1.4571 /
SS 316 Ti
welded DN 80 50 215 165 200
Flange
(DIN 2633, E)
0120-0715-03
1.4571 /
SS 316 Ti
welded DN 100 60 220 170 205
Clamp
(TC L14 AM7)
0120-2918-08
1.4435 /
SS 316 L
Biotech 1" 40 96 160 195
Clamp
(TC L14 AM7)
0120-1946-08
1.4435 /
SS 316 L
Biotech 1.5" 40 106 160 195
Clamp
(TC L14 AM7)
0120-2914-08
1.4435 /
SS 316 L
Biotech 2" 40 112 160 195
Tab. 3 Sensor dimensions in dependence of specifications of standard sensor body
Process connection Part.-No. Material Design
Line
size
OPL A-A*)
[mm]
A
[mm]
B
[mm]
C
[mm]
Tab. 4 Cable weights
Cable Weight
Lamp cable (1.5 mm
2
)
0.9 kg / 10 m
Lamp cable (2.5 mm
2
)
1.2 kg / 10 m
Lamp cable (4.0 mm
2
)
1.5 kg / 10 m
Detector cable (TF16) 1.2 kg / 10 m
