Connection to converter C 4000
Tool • Screw driver
To be able to allocate the end splices unequivocally to the clamps of the
converter, each end splice is marked with the number of the correct clamp:
Detector cable to sensor
1 = white (A1) 2 = brown (A2) 5 = black (A5)
Detector cable to sensor (reference channel)
3 = white (C3) 4 = brown (C4) 5 = gray (C5)
Lamp cable to sensor
6 = white or blue (6) 7 = brown (7)
Caution!
Lamp voltage must be adjusted to the cable length in order to compensate
voltage loss in the cable. Too low lamp voltage can lead to wrong measuring
results. Too high lamp voltage reduces the life of the lamp module considerably.
Follow the instructions in the instruction manual of the converter. During
operation, voltage at the lamp is 4.8 V.
2 sensors
TF16
TF16
A / C
B / D
E
F
250 m / 820 ft
2 sensors
AF26
TF16
A / C
B / D
E
F
250 m / 820 ft
2 sensors
AF45
TF16
A / C
B / D
E
F
100 m / 328 ft
250 m / 820 ft
3 sensors
2 x AS56
TF16
A / C
B / D
E
F
50 m / 164 ft.
250 m / 820 ft
Tab. 9 Connections
Number of
sensors sensor
type
Detector input connection of the converters
Lamp
output
Cable length max.
C4101 C4121 C4201 C4221 C4202 C4222 C4322 C4422
